Health and Social Care Information Centre
NHS Data Model and Dictionary Service
Type: | Patch |
Reference: | 1548 |
Version No: | 1.0 |
Subject: | September 2015 Release Patch |
Effective Date: | Immediate |
Reason for Change: | Patch |
Publication Date: | 24 September 2015 |
Background:
This patch updates the NHS Data Model and Dictionary in preparation for the September 2015 Release and includes:
- What's New amended to include Change Requests incorporated since the last version of the NHS Data Model and Dictionary was published
- Missing hyperlinks added
- Website links updated
- HTML format corrected
- Retired Attribute removed from Care Contact Class.
To view a demonstration on "How to Read an NHS Data Model and Dictionary Change Request", visit the NHS Data Model and Dictionary help pages at: http://www.datadictionary.nhs.uk/Flash_Files/changerequest.htm.
Note: if the web page does not open, please copy the link and paste into the web browser.
Summary of changes:
Date: | 24 September 2015 |
Sponsor: | Richard Kavanagh, Head of Data Standards - Interoperability Specifications, Architecture, Standards and Innovation, Health and Social Care Information Centre |
Note: New text is shown with a blue background. Deleted text is crossed out. Retired text is shown in grey. Within the Diagrams deleted classes and relationships are red, changed items are blue and new items are green.
Click here for a printer friendly view of this page.
Change to Data Set: Changed Description
Cover of Vaccination Evaluated Rapidly (COVER) Data Set Overview
The Cover of Vaccination Evaluated Rapidly (COVER) Data Set has been incorporated early to allow users to see the changes, but please note the implementation date is 1st October 2015.
Change to Supporting Information: Changed Description
The Commissioning Data Set Addressing Grid below illustrates which ORGANISATION CODES should be used to populate the CDS PRIME RECIPIENT IDENTITY and CDS COPY RECIPIENT IDENTITY for each PATIENT / NHS SERVICE AGREEMENT. See the specific ORGANISATION CODE Data Elements for further information on their usage and Organisation Data Service Default Codes etc.
Health Care Providers need to specify the ORGANISATIONS that have a right to the commissioning data set data as a CDS PRIME RECIPIENT IDENTITY or CDS COPY RECIPIENT IDENTITY. This is so that they can access the data once it has been stored in the Secondary Uses Service.
Please note that payment via the National Tariff Payment System is not determined by the CDS PRIME RECIPIENT IDENTITY or CDS COPY RECIPIENT IDENTITY.
Important Notes:
- The CDS PRIME RECIPIENT IDENTITY must be allocated on the first creation and submission of a CDS Type for a PATIENT and must not change even if the ADDRESS or ORGANISATION CODE (RESIDENCE RESPONSIBILITY) of the PATIENT changes during the lifetime of the Commissioning Data Set record otherwise duplicate Commissioning Data Set data may be lodged in the Secondary Uses Service database.
See the supporting information in Commissioning Data Set Submission Protocol for a detailed explanation. - Note that if two recipients are identical for example, the ORGANISATION CODE (RESIDENCE RESPONSIBILITY) may be the same as the ORGANISATION CODE (CODE OF COMMISSIONER), only one entry for that ORGANISATION should be made for that recipient.
- Specialised service ACTIVITY commissioned by a regional Specialised Commissioning Group should include their ORGANISATION CODE as a CDS COPY RECIPIENT IDENTITY. ACTIVITY commissioned by a shared service ORGANISATION or other consortium of Primary Care Trusts, should similarly include the ORGANISATION CODE of the shared service or the lead Primary Care Trust, if this does not already appear as a CDS COPY RECIPIENT IDENTITY or CDS PRIME RECIPIENT IDENTITY.
Commissioning Data Set Addressing Grid for users of Commissioning Data Set version 6-2 onwards
Notes:
*Key to population codes:
M - This Data Element is mandatory in the CDS-XML schema. Submissions will not flow if this Data Element is absent
O - This Data Element is optional.** Specialised Services and Other Commissioning Consortia Service Agreements include SERVICES that are commissioned by regional Specialised Commissioning Groups and local arrangements for commissioning ACTIVITY through shared service ORGANISATIONS.
For supplementary information on the Commissioning Data Sets, see theNHS Data Model and Dictionary website.
Change to Supporting Information: Changed Description
|
This page contains information on the following subjects:
Commissioning Data Sets The Commissioning Data Set is the basic structure used for the submission of commissioning data to the Secondary Uses Service. Every secondary care provider in England has to send a set of standard Commissioning Data Sets to the Secondary Uses Service which contains details of all the care they have provided. Each Commissioning Data Set name is in Title Case and where the name of a Data Set is Aqua Blue, it indicates that it is a hyperlink and if clicked on will display the Data Set. To access a Commissioning Data Set,:
Further guidance on the layout of the Commissioning Data Sets can be found at: Commissioning Data Set Redesign Guidance Notes. There are three frames to each Commissioning Data Set:
Commissioning Data Set Supporting Information Further information relating to Commissioning Data Sets can be accessed from the Commissioning Data Sets menu in the "Left Hand Frame". This section provides help and guidance for transmitting the Commissioning Data Sets to the Secondary Uses Service, for example, the XML Schema TRUD Download. The Commissioning Data Set XML Schema, documentation and Release Notes can be downloaded via this page. Note: XML based messaging has been mandated as the standard to be used for transmitting the Commissioning Data Sets. The XML Schema defines the nationally agreed data specification. Schema Documentation The Commissioning Data Set XML Message Schema is a technical document that is designed for use by anyone setting up and maintaining systems to flow Commissioning Data Sets. It offers a visual representation of the actual XML Schema against which the data is validated. This provides:
Supporting Data Sets Supporting Data Sets are subsets of Commissioning Data Sets and can be accessed from the Front Page as with any other Data Sets, for example, the Critical Care Minimum Data Set. All relevant Commissioning Data Sets can be accessed by clicking on the hyperlinks from this Data Set. What would you like to do next?
|
Change to Supporting Information: Changed Description
The Commissioning Data Sets submitted by providers carry information to determine the update method to be used by the Secondary Uses Service in order to update the national database.
These update rules are known as the Commissioning Data Set Submission Protocol and the set of data controls used to indicate this are carried in the Commissioning Data Set Transaction Header Group which must be present and correct in every CDS Type submitted to the Secondary Uses Service.
Two Update Mechanisms are available:
- Net Change - to support the management of an individual CDS Type in the Secondary Uses Service database and enables Commissioning data to be inserted/ updated or deleted.
CDS Senders are expected to use the Net Change Update Mechanism wherever possible. - Bulk Replacement - to support the management of bulk commissioning data for an identified CDS BULK REPLACEMENT GROUP CODE of data for a specified time period and for a specified CDS PRIME RECIPIENT IDENTITY.
CDS Senders should only use the Bulk Replacement Update Mechanism in exceptional circumstances.
It is strongly advised that all ORGANISATIONS should, as a minimum process, commence migration to use the CDS-XML Version 6 Message for weekly Net Change submissions by March 2009.
Net Change:
Net Change processes are managed by specific data settings as defined in the CDS V6-2 Type 005N - Commissioning Data Set Transaction Header Group - Net Change Protocol option of the CDS Transaction Header Group. The Secondary Uses Service uses the following data to manage the database:
Each CDS Type must have a CDS UNIQUE IDENTIFIER which must be uniquely maintained for the life of that Commissioning Data Set record. This is a particular consideration where mergers and/or healthcare systems are changed or upgraded, see Commissioning Data Set Submission and Organisation Mergers. Any change to the CDS UNIQUE IDENTIFIER during the "lifetime" of a Commissioning Data Set record will almost certainly result in a duplicate record being lodged in the Secondary Uses Service database.
A Commissioning Data Set record delete transaction must be sent to the Secondary Uses Service database when any previously sent Commissioning Data Set record requires deletion/removal, for example to reflect Commissioner changes etc.
Where CDS UPDATE TYPE 1 is required (delete/cancellation), an empty XML element called 'Delete Transaction' can be used instead of submitting he original CDS Type record, after the CDS V6-2 Type 005N - CDS Transaction Header Group - Net Change Protocol. See the CDS V6-2- XML Schema-Release Notes-v1-0. See the CDS V6-2- XML Schema Release Notes which can be downloaded via the XML Schema TRUD Download page.
The CDS APPLICABLE DATE and CDS APPLICABLE TIME must be used to ensure that all Commissioning data is updated in the Secondary Uses Service database in the correct chronological order.
The CDS SENDER IDENTITY must not change during the lifetime of the CDS data.
This is particularly significant for multiple and/or merged organisations, and for those services who submit data on behalf of another NHS Trust, NHS Foundation Trust or Independent Sector Healthcare Provider.
Bulk Replacement
Bulk Replacement processes are managed by specific data settings as defined in the CDS V6-2 Type 005B - Commissioning Data Set Transaction Header Group - Bulk Update Protocol option of the CDS Transaction Header Group. The Secondary Uses Service uses the following data to manage the database:
- CDS SENDER IDENTITY
- CDS BULK REPLACEMENT GROUP CODE
- CDS EXTRACT DATE
- CDS EXTRACT TIME
- CDS REPORT PERIOD START DATE
- CDS REPORT PERIOD END DATE
- CDS PRIME RECIPIENT IDENTITY
Every CDS Type must be submitted using the correct CDS BULK REPLACEMENT GROUP CODE.
The CDS REPORT PERIOD START DATE and the CDS REPORT PERIOD END DATE, (i.e. the effective date period), must be valid and consistent, and reflect the dates relevant to the Commissioning data contained in the interchange.
The CDS SENDER IDENTITY must not change during the lifetime of the Commissioning Data Set record. This is particularly significant for multiple and/or merged organisations, and for those services who submit data on behalf of another ORGANISATION.
The CDS PRIME RECIPIENT IDENTITY must be identified in each Commissioning Data Set and must not be changed during the lifetime of the Commissioning Data Set record otherwise the data stored in the Secondary Uses Service database may lose its integrity (e.g. duplicate Commissioning data may be stored).
For this reason it is advised that the ORGANISATION CODE (RESIDENCE RESPONSIBILITY) should always be used to determine the CDS PRIME RECIPIENT IDENTITY as detailed in the Commissioning Data Set Addressing Grid. Senders must also be aware that if the ORGANISATION CODE (RESIDENCE RESPONSIBILITY) is itself derived from the PATIENT's POSTCODE OF USUAL ADDRESS then great care must be taken to manage all elements of this relationship.If it is necessary to change any of this data during the lifetime of a Commissioning Data Set record, then the Secondary Uses Service help desk should be contacted for advice.
It is strongly advised that users of the Bulk Replacement Mechanism maintain a correctly generated CDS UNIQUE IDENTIFIER within the Commissioning data. This will establish a migration path towards the use of the Net Change Mechanism and will also then minimise the risk of creating duplicate Commissioning Data Set data.
Sub contracting
If a Health Care Provider sub-contracts healthcare provision and its associated Commissioning Data Set submission to a second ORGANISATION (eg a different Health Care Provider or a Shared Services Organisation), arrangements to submit the Commissioning Data Set data must be made locally to ensure that only one ORGANISATION sends the Commissioning Data Set data to the Secondary Uses Service.
If the second ORGANISATION wishes to add other Commissioning data to the Secondary Uses Service database to that already submitted by the first ORGANISATION, both parties need to ensure that a different CDS SENDER IDENTITY is used. Often this is done by changing the last 2 digits of the 5 digit code (the Site element of the ORGANISATION CODE).
Note: Data sent using the same CDS SENDER IDENTITY by two different parties will most likely overwrite each other's data in the Secondary Uses Service database. Further advice can be obtained from the Secondary Uses Service helpdesk.
Users should be aware of how the 15 character code of their CDS INTERCHANGE SENDER IDENTITY (also known as the EDI Address) is created. This may depend on how their XML interface solution has been set up. It may not be possible to rely on a change to the ORGANISATION CODE (CODE OF PROVIDER) in order to change the CDS INTERCHANGE SENDER IDENTITY should this become necessary.
Change to Supporting Information: Changed Description
Copyright ©2013 Health and Social Care Information Centre.Copyright © Health and Social Care Information Centre.
For more guidance on copyright see www.hscic.gov.uk/terms-and-conditions.
If you have any queries on copyright and crown copyright, please contact the Data Access and Information Sharing team: dais@hscic.gov.uk.
Change to Supporting Information: Changed Description
Contextual Overview Contextual Overview
The Female Genital Mutilation Data Set provides essential information in relation to the female genital mutilation population across England.The Female Genital Mutilation Data Set provides essential information in relation to the female genital mutilation population across England.
The Female Genital Mutilation Data Set is used:
- To publish Official Statistics which will inform the Department of Health, NHS England, other Government Agencies and the public, about female genital mutilation when it has been identified
- To identify the potential risk of female genital mutilation to young girls and vulnerable women
- For better planning and management of female genital mutilation SERVICES at a local level and across England
Data may be input immediately using an input screen via the HSCIC Clinical Audit Platform when female genital mutilation is identified, or data extracts for Patients, can be submitted as a bulk upload on a monthly basis for each ORGANISATION.
CARE CONTACT activities undertaken for female genital mutilation PATIENTS during the REPORTING PERIOD are reported in the data upload. This includes any attendances at an Out-Patient Clinic led by any type of CARE PROFESSIONAL, Hospital Provider Spells, Accident and Emergency Attendances, Group Therapy, Ward Attendances; or any other type of direct PATIENT-facing CARE CONTACT.
The associated SNOMED CT Subsets for the Female Genital Mutilation Data Set are listed below:
- Female genital mutilation related findings - Original ID 58681000000133
- Female genital mutilation related procedures - Original ID 58671000000131
DATA EXTRACT SPECIFICATION
Description:
The Department of Health requires all NHS Trusts, NHS Foundation Trusts and GENERAL MEDICAL PRACTITIONERS to generate and provide a data extract in accordance with the Female Genital Mutilation Data Set. This requirement is applicable to all CARE PROFESSIONALS in these ORGANISATIONS whenever it has been identified that a woman or young girl has indergone female genital mutilation. This requirement is applicable to all CARE PROFESSIONALS in these ORGANISATIONS whenever it has been identified that a woman or young girl has undergone female genital mutilation.
Time period:
Data extracted from systems can be submitted as a bulk upload on a monthly basis for each ORGANISATION.
Format:
Data submitted by the bulk upload facility must be formatted in 3 separate comma separated variable (csv) files (i.e. Patient, Attendance or Female Genital Mutilation), which are used to populate the Health and Social Care Information Centre Clinical Audit Platform. The data elements should be transmitted in the order specified in the Female Genital Mutilation Data Set.
Transmission
Electronic files must be transmitted to the Health and Social Care Information Centre via the Clinical Audit Platform which is a secure web portal.
Connection to the web portal requires registration to the Clinical Audit Platform, which will include the provision of a login account name and password.
Further information about the Clinical Audit Platform and the data upload facility can be found on the Clinical Audit Platform web pages on the Health and Social Care Infomation Centre website.Further information about the Clinical Audit Platform and the data upload facility can be found on the Clinical Audit Platform web pages on the Health and Social Care Information Centre website.
Further guidance on the Female Genital Mutilation Data Set can be found on the Standardisation Commitee for Care Information publication web pages on the Health and Social Care Information Centre website.Further guidance on the Female Genital Mutilation Data Set can be found on the Standardisation Committee for Care Information publication web pages on the Health and Social Care Information Centre website.
Change to Supporting Information: Changed Description, Name
Information Standards Notices and Data Dictionary Change Notices incorporated into the NHS Data Model and Dictionary:
Release: September 2015
- CR1521 (Immediate) - SCCI1580 Palliative Care Co-ordination: Core content (Formerly End of Life Care)
- CR1552 (Immediate) - DDCN 1522/2015 Update General Dental Council Registration Number
- CR1530 (Immediate) - ISB 0158 Retirement of Ambulance Services (KA34) Central Return Data Set
- CR1528 (Immediate) - ISB 1568 Retirement of KO41 (A) Hospital and Community Health Service Complaints and KO41 (B) General Practice (including Dental) Complaints Central Return Forms
- CR1551 (Immediate) - ISB 0133 Retirement of HPV Immunisation Programme Vaccine Monitoring Monthly Minimum Data Set and HPV Immunisation Programme Vaccine Monitoring Annual Minimum Data Set
Release: August 2015
- CR1374 (1 September 2015) - SCCI1510 Community Information Data Set Update
- CR1356 (1 September 2015) - SCCI1069 Children and Young People’s Health Services Data Set Update and XML Schema
- CR1529 (Immediate) - DDCN 1529/2015 Change to the Mechanism for XML Schema Publication and Download
- CR1543 (Immediate) - DDCN 1543/2015 Treatment Function Code: 840 Audiology
Release: July 2015
- CR1475 (Immediate) - SCCI1605 Accessible Information
Release: June 2015
- CR1518 (Immediate) - ISB 092 CDS 6-1 Retirement
- CR1525 (Immediate) - DDCN 1525/2015 Burden Advice and Assessment Service (BAAS)
- CR1524 (Immediate) - DDCN 1524/2015 Updating of Activity Location Type and Source of Admission Attributes
- CR1505 (Immediate) - DDCN 1505/2015 Death Cause Information
Release: May 2015
- CR1507 (Immediate) - DDCN 1507/2015 To add SUS CDS business rule H4 text
Release: April 2015
- CR 1494 and CR 1506 (1 April 2015) - SCCI2026 Amd 12/2014 Female Genital Mutilation Data Set and Retirement of Female Genital Mutilation Prevalence Data Set
- CR1513 (27 April 2015) - DDCN 1513/2015 Introduction of NHS England Region (Geography)
- CR1509 (1 April 2015) - ISB 1513 Maternity Services Data Set
CR1509 is a corrigendum to CR1355 (1 November 2014) - ISB 1513 Amd 45/2012 Maternity Services Data Set Update and XML Schema published in the October 2014 release
Release: March 2015
- CR1492 (1 April 2015) - SCCI1521 Amd 17/2014 Updates to the Cancer Outcomes and Services Data Set and XML Schema
Release: February 2015
- CR1486 (27 February 2015) - ISB 0090 Amd 9/2014 Organisation Data Service – Health and Justice Organisation Identifiers
Due to a delay in the Organisation Data Service (ODS) February release, the implementation date is now 6 March 2015.
Release: January 2015
- CR1473 (1 January 2015) - ISB 1538 Amd 13/2014 Chlamydia Testing Activity Data Set Update
- CR1496 (Immediate) - DDCN 1496/2015 Clinical Coding
Release: December 2014
- CR1396 (31 October 2014) - ISB 1567 Amd 15/2014 National Joint Registry Data Set Version 6
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 October 2015:
- CR1487 (1 October 2015) - ISB 0089 Amd 8/2014 Cover of Vaccination Evaluated Rapidly (COVER) Central Return Data Set
Release: November 2014
- CR1420 (Immediate) - ISB 0139 Amd 29/2013 Genitourinary Medicine Clinic Activity Data Set (GUMCAD) Update
- CR1421 (Immediate) - ISB 1518 Amd 30/2013 Sexual and Reproductive Health Activity Data Set (SRHAD) Update
- CR1422 (Immediate) - ISB 1518 Amd 30/2013 Retirement of Central Return Form KT31 Cross Sector Services
Release: October 2014
- CR1355 (1 November 2014) - ISB 1513 Amd 45/2012 Maternity Services Data Set Update and XML Schema
Release: September 2014
- CR1484 (Immediate) - DDCN 1484/2014 Female Genital Mutilation SNOMED CT Subsets
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 31 July 2015:
- CR1344 (31 July 2015) - ISB 1594 Amd 31/2012 Information Sharing to Tackle Violence Minimum Data Set
Release: August 2014
- CR1360 (1 September 2014) - ISB 0011 Amd 5/2014 Mental Health and Learning Disabilities Data Set
Release: July 2014
- CR1351 (1 July 2014) - ISB 1520 Amd 02/2013 Improving Access to Psychological Therapies Data Set Version 1.5
- CR1482 (Immediate) - DDCN 1482/2014 Source of Referral for Mental Health
- CR1480 (Immediate) - DDCN 1480/2014 Mental Health Care Cluster 9
- CR1477 (Immediate) - DDCN 1477/2014 Payment by Results
- Note: CR1383 (31 December 2014) - ISB 1555 Amd 10/2012 Personal Demographics Service Birth Notification Data Sets
At the Standardisation Committee for Care Information meeting on 28th May 2014, an amendment to the implementation date of the ISB information standard was approved. The implementation date is now 31 December 2014.
- The July 2014 Release updates the NHS Data Model and Dictionary Help Pages to reflect the new organisation structure.
Release: June 2014
- CR1465 (Immediate) - DDCN 1465/2014 Primary Care Trusts and NHS Trusts
- CR1461 (Immediate) - DDCN 1461/2014 New Standardisation Committee for Care Information (SCCI) Process
- CR1383 (30 June 2014) - ISB 1555 Amd 10/2012 Personal Demographics Service Birth Notification Data Sets
Release: May 2014
- CR1353 (1 June 2014) - ISB 1067 Amd 22/2013 Workforce Data Set Version 2.7
Release: April 2014
- CR1449 (Immediate) - ISB 1610 Amd 01/2014 Female Genital Mutilation Prevalence Data Set
Release: March 2014
- CR1388 (1 April 2014) - ISB 1521 Amd 23/2013 Updates to the Cancer Outcomes and Services Data Set and XML Schema
- CR1370 (1 April 2014) - ISB 1533 Amd 24/2013 Updates to the Systemic Anti-Cancer Therapy Data Set and XML Schema
- CR1322 (1 April 2014) - ISB 0111 Amd 26/2012 Changes to the Radiotherapy Data Set
- CR1387 (1 April 2014) - ISB 0084 Amd 10/2013 Introduction of OPCS-4.7
- CR1376 (1 April 2014) - ISB 1607 Amd 26/2013 Emergency Care Weekly Situation Report Data Set
- CR1433 (Immediate) - DDCN 1433/2014 Data Services for Commissioners
- CR1467 (1 April 2014) - DDCN 1467/2014 Retirement of Standards
- CR1464 (1 April 2014) - DDCN 1464/2014 Retirement of Standards - Domains and Diagrams
- CR1458 (1 April 2014) - DDCN 1458/2014 Retirement of Standards - DSCNs - 11/97/P05, 12/97/P06, 15/97/P09, 18/97/P12, 22/96/P19, 32/96/P27, 49/97/P35, 62/95/P51, 07/2007, 08/2009, 17/92, 20/2001, 22/2006 and 38/2002
- CR1444 (1 April 2014) - DDCN 1444/2014 Retirement of Standards
- CR1436 (1 April 2014) - DDCN 1436/2014 Retirement of Standards
- CR1435 (1 April 2014) - DDCN 1435/2014 Retirement of Standards - DSCNs 22/95/P21, 20/91, 21/93, 40/95/P34, 09/94/P04, 93/95/P76, 23/94/A04, 8/92 and 17/93
- CR1432 (1 April 2014) - DDCN 1432/2014 Retirement of Standards - DSCN 3/92, DSCN 12/96/P11, DSCN 50/94/P36, DSCN 66/96/W09 and DSCN 16/93
- CR1429 (1 April 2014) - DDCN 1429/2014 Retirement of Standards - DSCN 07/96/P06
- CR1425 (1 April 2014) - DDCN 1425/2014 Retirement of Standards
- CR1423 (1 April 2014) - DDCN 1423/2014 Retirement of Standards - DSCNs 37/98/A09, 14/97/P08, 12/2002, 37/2003, 14/2004 and 27/2001
- CR1419 (1 April 2014) - DDCN 1419/2014 Retirement of Standards - DSCNs 39/98/A11, 09/99/P06, 11/99/P07, 13/2003, 38/2001, 22/2001, 19/98/A02, 40/96/P34, 29/94/P19, 49/94/P35, 34/95/P29, 53/96/P44 and 96/95/P79
- CR1418 (1 April 2014) - DDCN 1418/2014 Retirement of Standards
- CR1417 (1 April 2014) - DDCN 1417/2014 Retirement of Standards - DSCNs 13/95/P12, 44/2001, 29/2004, 18/98/W02 and 24/98/F01
- CR1416 (1 April 2014) - DDCN 1416/2014 Retirement of Standards - KC64 - DSCNs 05/98/P05 and 26/95/W02
- CR1414 (1 April 2014) - DDCN 1414/2014 Retirement of Standards - DSCNs 03/99/P03, 10/2002, 12/99/A04, 20/98/A03, 30/98/P21, 35/99/P25, 37/97/P24 and 43/97/P29
- CR1413 (1 April 2014) - DDCN 1413/2014 Retirement of Standards - DSCNs 13/97/P07, 15/96/P14, 17/2001, 20/2004, 21/2001, 21/2003, 28/98/P20, 33/2003 and 43/2002
- CR1409 (1 April 2014) - DDCN 1409/2014 Retirement of Standards - DSCN's 46/97/P32, 01/2004, 04/2004, 11/2005, 27/2002, 31/2002, 53/2002 and 54/2002
Release: February 2014
- CR1460 (Immediate) - DDCN 1460/2014 NHS Dental Services Update
- CR1459 (Immediate) - DDCN 1459/2014 General Medical Practitioner (Specified), Doctor Index Number and General Medical Practitioner PPD Code Update
- CR1446 (Immediate) - DDCN 1446/2014 Health and Social Care Information Centre Update
- CR1404 (Immediate) - DDCN 1404/2014 Retirement of e-Gif definitions
- CR1395 (28 February 2014) - ISB 0090 Amd 17/2013 Organisation Data Service – NHS Postcode Directory
Release: January 2014
- CR1386 (31 January 2014) - ISB 0090 Amd 9/2013 Special Health Authority (SpHA) Code Structure Change
- CR1443 (Immediate) - DDCN 1443/2014 Change of name of the National Institute for Health and Clinical Excellence
- CR1441 (Immediate) - DDCN 1441/2014 Retirement of Review of Central Returns (ROCR) - Central Return Form KH03A
- CR1440 (Immediate) - DDCN 1440/2014 Retirement of Review of Central Returns (ROCR) - Genitourinary Medicine Access Monthly Monitoring Data Set
- CR1439 (Immediate) - DDCN 1439/2013 Retirement of Review of Central Returns (ROCR) Returns
- CR1405 (Immediate) - DDCN 1405/2013 Overseas Visitors
- CR1393 (Immediate) - DDCN 1393/2013 Amendment to Inter-Provider Transfer Administrative Minimum Data Set Overview
- CR1392 (Immediate) - DDCN 1392/2013 Review of Central Returns (ROCR) Discontinuations - Referral to Treatment Performance Sharing Data Set
- CR1391 (Immediate) - DDCN 1391/2013 Review of Central Returns (ROCR) Discontinuations - Referral to Treatment (RTT) Summary Patient Tracking List Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 June 2014:
- CR1346 (1 June 2014) - ISB 1595 Amd 32/2012 National Neonatal Data Set
Release: November 2013
- CR1424 (Immediate) - DDCN 1424/2013 Application Identifier (GS1)
- CR1367 (29 November 2013) - ISB 0090 Amd 5/2013 Organisation Data Service - Introduction of New Sub Type Identifier for Private Dental Practices
- CR1359 (29 November 2013) - ISB 0090 Amd 47/2012 Organisation Data Service - Identification Codes for Local Authorities
- CR1407 (Immediate) - DDCN 1407/2013 Clinical Investigations
- CR1415 (Immediate) - DDCN 1415/2013 Area Teams
- CR1411 (Immediate) - DDCN 1411/2013 Update to Supporting Information: SNOMED CT®
Release: September 2013
- CR1348 (1 October 2013) - ISB 1597 Amd 35/2012 Breast Screening Programmes Data Set (KC63 and KC62)
- CR1403 (Immediate) - DDCN 1403/2013 Religious or Other Belief System Affiliation
- CR1384 (Immediate) - DDCN 1384/2013 Health and Social Care Information Centre Rebranding of XML Schemas
- CR1397 (Immediate) - DDCN 1397/2013 Retired Main Specialty Codes
Release: July 2013
- CR1377 (Immediate) - ISB 0105 Retirement of Accident and Emergency Quarterly Monitoring Data Set (QMAE)
Release: May 2013
- CR1363 (Immediate) - ISB 1067 Amd 43/2012 National Workforce Data Set Version 2.6
- CR1382 (Immediate) - DDCN 1382/2013 National Renal Data Set amendment
- CR1381 (Immediate) - DDCN 1381/2013 Healthcare Resource Groups
- CR1235 (1 June 2013) - ISB 1588 Amd 11/2012 Accident and Emergency Clinical Quality Indicators
Release: April 2013
- CR1372 (Immediate) - DDCN 1372/2013 Organisation Update: April 2013
- CR1369 (Immediate) - DDCN 1369/2013 Organisation Codes and Organisation Types
- CR1347 (1 April 2013) - ISB 1521 Amd 40/2012 Updates to the Cancer Outcomes and Services Data Set and XML Schema
Release: March 2013
- CR1364 (Immediate) - DDCN 1364/2013 Operating Theatre
- CR1335 (1 April 2013) - ISB 1593 Amd 27/2012 Venous Thromboembolism Risk Assessment Data Set
- CR1340 (1 April 2013) - ISB 0090 Amd 37/2012 Organisation Data Service - Non-Legislative Organisations
- CR1321 (1 April 2013) - ISB 0011 Amd 25/2012 Mental Health Minimum Data Set version 4.1
Release: February 2013
- CR1336 (Immediate) - DDCN 1336/2013 XML Schema Constraint Pages
- CR1362 (Immediate) - DDCN 1362/2013 Update to Organisations in the NHS Data Model and Dictionary
- CR1246 (Immediate) - DDCN 1246/2013 Guidance for Merging Organisations
- CR1345 (Immediate) - DDCN 1345/2013 e-Government Interoperability Framework (e-GIF) and Government Data Standards Catalogue
- CR1354 (Immediate) - DDCN 1354/2013 Treatment Function Code - Well Babies
Release: December 2012
- CR1155 (Immediate) - ISB 1567 Amd 12/2011 National Joint Registry Data Set Version 5
- CR1324 (1 December 2012) - ISB 1067 Amd 23/2012 Workforce Data Set Version 2.5
- CR1196, CR1287 and CR1195 (1 January 2013) - ISB 1521 Amd 64/2010 Cancer Outcomes and Services Data Set, Cancer Outcomes and Services Data Set Message and Retirement of Cancer Registration Data Set and National Cancer Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
- CR1337 (1 April 2013) - ISB 1072 Amd 30/2012 Update to Child and Adolescent Mental Health Services Secondary Uses Data Set
Release: November 2012
- CR1166, CR1167 and CR1306 (1 November 2012) - ISB 0092 Amd-16-2010 Commissioning Data Set Version 6-2, Commissioning Data Set XML Message Version 6-2 and Retirement of CDS 6-0
- CR1305 (1 April 2013) - ISB 0092 Amd 06/2011 Allied Health Professions Referral to Treatment (AHP RTT) Update - CDS 6-2
- CR1286 (1 November 2012) - ISB 0028 Amd 17/2012 Treatment Function Codes Update
- CR1343 (Immediate) - DDCN 1343/2012 Change of name for NHS Commissioning Board Authority
- CR1342 (Immediate) - DDCN 1342/2012 Overseas Visitors Update
- CR1341 (Immediate) - DDCN 1341/2012 Discharge Default Code Descriptions
- CR1323 (Immediate) - National Cancer Waiting Times Monitoring Data Set Update for "Delay Reason To Treatment For Cancer"
CR1323 is a corrigendum to CR1258 (1 July 2012) - ISB 0147 Amd 23/2011 Changes to the National Cancer Waiting Times Monitoring Data Set published in the June 2012 release
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
- CR1231 and CR1288 (1 April 2013) - ISB 1570 Amd 164/2010 HIV and AIDS Reporting Data Set and HIV and AIDS Related Data Set Message
Release: September 2012
- CR1103 (Immediate) - ISB 0066 Amd 43/2010 Renal Data Set - Data Item Addition, Changes and Deletions
- CR1334 (Immediate) - DDCN 1334/2012 Psychology Definitions
- CR1331 (Immediate) - DDCN 1331/2012 Activity Date Time Type
- CR1329 (Immediate) - DDCN 1329/2012 Change of name for "Health and Social Care Information Centre"
Release: August 2012
- CR1326 (Immediate) - DDCN 1326/2012 Health and Care Professions Council
- CR1241 (Immediate) - DDCN 1241/2012 NHS dictionary of medicines and devices
- CR1292 (Immediate) - ISB 1549 Amd 4/2011 and DDCN 1292/2012 Deprecation and withdrawal of version 3.2 of the Acute Myocardial Infarction Data Set and subsequent retiring of the Data Set from the NHS Data Model and Dictionary
Release: June 2012
- CR1314 (Immediate) - DDCN 1314/2012 Reasonable Offer Update
- CR1282 (29 June 2012) - ISB 0090 Amd 36/2011 Independent Sector Healthcare Provider (ISHP) Codes extended for ISHPs and Sites
- CR1258 (1 July 2012) - ISB 0147 Amd 23/2011 Changes to the National Cancer Waiting Times Monitoring Data Set
Release: May 2012
- CR1215 (1 June 2012) - ISB 1067 Amd 30/2011 National Workforce Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
- CR1028 (1 April 2013) - ISB 1069 Amd 14/2012 Children and Young People's Health Services Data Set
- CR1029 (1 April 2013) - ISB 1072 Amd 12/2012 Child and Adolescent Mental Health Services (CAMHS) Data Set
- CR1104 (1 April 2013) - ISB 1513 Amd 13/2012 Maternity Secondary Uses Data Set
Release: March 2012
- CR1242 (Immediate) - DDCN 1242/2012 Retirement of Mental Health Minimum Data Set Version 3
- CR1238 and CR1276 (1 April 2012) - ISB 1577 Amd 10/2011 Diagnostic Imaging Data Set and Diagnostic Imaging Data Set Message v 1-0
- CR1290 (Immediate) - DDCN 1290/2012 Data Set Notation
- CR1263 (Immediate) - ISB 0090 Amd 5/2012 Health and Social Care Bill Changes
- CR1255 (31 March 2012) - ISB 1576 Amd 08/2011 Quarterly Bed Availability and Occupancy Data Set
- CR1295 (Immediate) - Retirement of old Commissioning Data Set messages
The Information Standards Board for Health and Social Care have been involved in the redesign and retirement of the old Commissioning Data Set Pages, however a formal Information Standard and Collection (including Extraction) Notice (ISCE) will not be published as there are no changes to data standards.
Release: January 2012
- CR1285 (Immediate) - DDCN 1285/2012 Elective Admission Type
- CR1252 (Immediate) - DDCN 1252/2011 Geographic Area Changes
Release: November 2011
- CR1264 (Immediate) - ISB 1077 Amd 3/2012 Automatic Identification and Data Capture (AIDC) for Patient Identification Data Set
- CR1274 (Immediate) - DDCN 1274/2011 CDS Prime Recipient Identity Update
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
- CR1265 (1 April 2012) - ISB 1520 Amd 29/2011 Changes to the Improving Access to Psychological Therapies Data Set
Release: October 2011
- CR1271 (Immediate) - DDCN 1271/2011 Commissioning Data Set Addressing Grid Update
- CR1268 (Immediate) - DDCN 1268/2011 Sexual Orientation Code
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
- CR1158 and CR1260 (1 April 2012) - ISB 1533 Amd 63/2010 Systemic Anti-Cancer Therapy Data Set and Systemic Anti-Cancer Therapy Data Set Message Schema
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 July 2012:
- CR1270 (1 July 2012) - ISB 1080 Amd 25/2011 Amendments to NHS Health Check Data Set
- CR1250 (1 July 2012) - ISB 1080 Amd 25/2011 NHS Health Checks Data Set Message Schema Version 2.0.0
Release: August 2011
- CR1232 (Immediate) - ISB 0034 Amd 26/2006 Systematized Nomenclature of Medicine Clinical Terms (SNOMED CT) - NHS Data Model and Dictionary Overview
- CR1222 (1 April 2012) - ISB 0021 Amd 86/2010 Introduction of the International Classification of Diseases Tenth Revision 4th Edition
- CR1190 (1 September 2011) - ISB 1538 Amd 131/2010 Chlamydia Testing Activity Data Set
- CR1188 (Immediate) - Amd 85/2010 Genitourinary Medicine Clinic Activity Data Set (GUMCAD) Extension to include Enhanced Sexual Health Services (ESHS)
The following data set is initially being introduced for local use only. A future Information Standard and Collection (including Extraction) Notice will be published to notify providers and system suppliers of the requirement to flow the data set nationally:
- CR1105 (1 April 2012) - ISB 1510 Amd 25/2010 Community Information Data Set
Release: July 2011
- CR1249 (Immediate) - DDCN 1249/2011 General Pharmaceutical Council Registration Changes
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 July 2012:
- CR1148 (1 July 2012) - ISB 1080 Amd 129/2010 NHS Health Checks Data Set
Release: June 2011
- CR1256 (Immediate) - DDCN 1256/2011 School Definitions
- CR1117 (26 August 2011) - ISB 0090 Amd 94/2010 Organisation Data Service Identification Codes for Local Authorities in England and Wales
- CR1251 (Immediate) - DDCN 1251/2011 Change to the Format/Length of Weekly Hours Worked
- CR1243 (Immediate) - DDCN 1243/2011 National Interim Clinical Imaging Procedure (NICIP) Code Set
Release: April 2011
- CR1154 (1 April 2011) - ISB 0011 Amd 87/2010 Mental Health Minimum Data Set Version 4.0
- CR1234 (Immediate) - DDCN 1234/2011 Technology Reference Data Update Distribution Service (TRUD)
- CR1168 (Immediate) - ISB 0097 Amd 140/2010 Genitourinary Medicine Access Monthly Monitoring Data Set Amendments - Removal of Human Immunodeficiency Virus data
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
- CR1050 (1 April 2012) - ISB 1520 Amd 51/2010 Improving Access to Psychological Therapies Data Set
Release: March 2011
- CR1224 (1 April 2011) - ISB 0092 Amd 02/20110 Commissioning Data Set Schema Version 6-1-1
- CR1223 (Immediate) - DDCN 1223/2011 Updates to Family Planning References
- CR1225 (Immediate) - DDCN 1225/2011 Practitioners with Special Interests
- CR1216 (1 April 2011) - ISB 0028 Amd 170/2010 Changes to Treatment Function Codes
- CR1203 (1 April 2011) - ISB 0084 Amd 150/2010 Introduction of OPCS Classification of Interventions and Procedures Version 4.6
Release: January 2011
- CR1116 (1 April 2010) - ISB 0003 Amd 79/2010 Immunisation Programmes Activity Data Set (KC50)
- CR1112 (1 April 2010) - ISB 1511 Amd 26/2010 NHS Continuing Healthcare and NHS Funded Nursing Care
- CR1068 (Immediate) - ISB 0133 Amd 161/2010 Change To Central Return: Human Papillomavirus (HPV) Immunisation Programme - Vaccine Monitoring Minimum Data Set
- CR1211 (Immediate) - DDCN 1211/2010 Commissioning Data Set Addressing Grid / Organisation Code (Code of Commissioner) Update
Release: December 2010
- CR1175 (1 April 2011) - ISB 1518 Amd 166/2010 Changes to Sexual and Reproductive Health Activity Data Set
- CR1198 (Immediate) - ISB 1067 Amd 165/2010 National Workforce Data Set
- CR1207 (01 December 2010) - ISB 1573 Amd 168/2010 Mixed-Sex Accommodation
- CR1149 (01 January 2011) - ISB 0139 Amd 99/2010 GUMCAD: Change to Genitourinary (GU) Episode Types
Release: November 2010
- CR1119 (Immediate) - DDCN 1119/2010 Organisation Codes Update
- CR1192 (Immediate) - DDCN 1192/2010 Change of name for "Health Solution Wales"
- CR1199 (Immediate) - DDCN 1199/2010 General Pharmaceutical Council and Royal Pharmaceutical Society of Great Britain Update
- CR1189 (Immediate) - DDCN 1189/2010 National Institute for Health and Clinical Excellence
- CR1187 (Immediate) - DDCN 1187/2010 Introduction of the Department for Education
Release: September 2010
- CR1128 (Immediate) - DDCN 1128/2010 Changes to reporting procedures for Overseas Visitors from the European Economic Area and Switzerland
- CR1173 (Immediate) - DDCN 1173/2010 Care Quality Commission Update
- CR1143 (Immediate) - DDCN 1143/2010 General Pharmaceutical Council
- CR1061 (1 October 2010) - ISB 0092/2010 CDS Type 20: Out-patient: Retirement of Default Codes for Out-patient Procedures
- CR1133 (Immediate) - ISB 00289/2010 National Specialty List
Release: August 2010
- The August 2010 Release introduces the NHS Data Model and Dictionary Help Pages.
Release: July 2010
- CR1134 (Immediate - ISB 1067/2010 Amd 109/2010 National Workforce Data Set
- CR1082 (Immediate) - ISB 0153/2010 Critical Care Minimum Data Set
- CR1121 (Immediate) - DSCN 17/2010 Retirement of Data Standard KC60 Central Return
Release: May 2010
- CR957 (Immediate) - DSCN 19/2010 Central Returns: KA34 Ambulance Services
- CR1069 (Immediate) - Redesign of the Commissioning Data Set Pages
The Information Standards Board for Health and Social Care have been involved in the redesign of the Commissioning Data Set Pages and are satisfied that it meets the requirements of the service, however a formal Information Standard and Collection (including Extraction) Notice (ISCE) will not be published as there are no changes to data standards.
Release: March 2010
- CR1123 (1 April 2010) - DSCN 18/2010 Information Standards Notice (ISN)
- CR1139 (Immediate) - DSCN 16/2010 Person Weight
- CR1130 (Immediate) - DSCN 15/2010 Change of name for "The NHS Information Centre for health and social care"
- CR1013 (April 2010) - DSCN 14/2010 Sexual and Reproductive Health Activity Dataset (SRHAD)
- CR1125 (Immediate) - DSCN 13/2010 NHS Data Model and Dictionary Maintenance Update - Policy Definitions
- CR1122 (Immediate) - DSCN 11/2010 Changes to Family Planning References
Release: January 2010
- CR1115 (Immediate) - DSCN 10/2010 Data Standards: Updating of e-Government Interoperability Framework and Government Data Standards Catalogue References
Release: December 2009
- CR1100 (Immediate) - DSCN 25/2009 NHS Prescription Services Update
- CR1045 (1 December 2009) - DSCN 17/2009 Referral to Treatment Clock Stop Administrative Event
- CR1003 (1 December 2009) - DSCN 16/2009 Commissioning Data Sets: Mandation of 18 Week Referral To Treatment Data Items
Release: November 2009
- CR1113 (Immediate) - DSCN 24/2009 Information Standards Board for Health and Social Care Update
- CR1087 (Immediate) - DSCN 23/2009 Health Professions Council Update
- CR1081 (Immediate) - DSCN 22/2009 Data Standards: NHS Data Model and Dictionary Maintenance Update
- CR1019 (27 November 2009) - DSCN 21/2009 Data Standards: Organisation Data Service (ODS) - Optical Sites and Optical Headquarters
- CR1034 (27 November 2009) - DSCN 20/2009 Data Standards: Organisation Data Service (ODS) - Care Homes in England and Wales and their Headquarters
Release: September 2009
- CR1065 (1 October 2009) - DSCN 15/2009 Data Standards: Organisation Data Service, Local Health Boards
Release: June 2009
- CR1014 (1 June 2009) - DSCN 13/2009 Religious and Other Belief System Affiliation
- CR1074 (Immediate) - DSCN 12/2009 Data Standards: Care Quality Commission
- CR1056 (Immediate) - DSCN 11/2009 Data Standards: NHS Data Model and Dictionary Maintenance Update
- CR1072 (1 December 2009) - DSCN 10/2009 Data Standards: National Radiotherapy Data Set
- CR1073 (Immediate) - DSCN 09/2009 Central Returns: Diagnostic Waiting Times and Activity Data Set
- CR1066 (Immediate) - DSCN 08/2009 Data Standards: NHS Prescription Services and NHS Dental Services
- CR1047 (1 April 2011) - DSCN 07/2009 Data Standards: Diabetic Retinopathy Screening Dataset v3.6
- CR1059 (Immediate) - DSCN 06/2009 Data Standard: National Workforce Data Set v2.1
- CR914 (April 2008 (Retrospective)) - DSCN 05/2009 NHS Stop Smoking Services Quarterly Monitoring Return
- CR899 (Immediate) - DSCN 02/2009 NHS Data Model and Dictionary Maintenance Update
Release: March 2009
- CR1001 (1 April 2009) - DSCN 03/2009 Introduction of Commissioning Data Set Schema Version 6-1 (2008-04-01) and update to Commissioning Data Set Schema Version 6-0 (2008-01-14)
- CR976 (31 March 2009) - DSCN 26/2008 Subject: KP90 - Admissions, Changes in Status and Detentions under the Mental Health Act
- CR1017 (1 April 2009) - DSCN 25/2008 Critical Care Minimum Data Set
- CR1002 (1 April 2009) - DSCN 24/2008 Data Standards: Introduction of Commissioning Dataset Version 6.1
- CR1016 (Immediate) - DSCN 23/2008 4 Byte Version of the Read Codes - Withdrawal
Release: December 2008
- CR1022 (1 January 2009) - DSCN 29/2008 Data Standards: 18 Weeks Referral to Treatment (RTT) Time, Performance Sharing
- CR901 (Immediate) - DSCN 28/2008 Removal of references to EDIFACT and the NHS Wide Clearing Service (NWCS)
- CR843 (1 April 2009) - DSCN 22/2008 Data Standards: National Radiotherapy Data Set
- CR1011 (1 January 2009) - DSCN 20/2008 Data Standards: National Cancer Waiting Times Minimum Data Set
Release: November 2008
- CR1026 (3 November 2008) - DSCN 21/2008 Information Standard: Mental Health Act 2007 Mental Category
Release: August 2008
- CR1018 (Immediate) - DSCN 19/2008 Data Standards: Change of Name for National Administrative Code Services (NACS) to Organisation Data Service (ODS)
- CR956 (1 September 2008) - DSCN 18/2008 Central Return: Human Papillomavirus (HPV) Immunisation Programme, Vaccine Monitoring Minimum Dataset
- CR861 (Immediate) - DSCN 16/2008 Central Return: Hospital and Community Services Complaints and General Practice (including Dental) Complaints - KO41(a) and KO 41(b)
- CR964 (Immediate) - DSCN 14/2008 Central Return: 18 Weeks ‘Adjusted’ Referral to Treatment (RTT) Dataset
- CR965 (Immediate) - DSCN 13/2008 Data Standards: Organisation Data Service (ODS) - Change to the Default Codes Set to Support Changes to GMS Contract
- CR879 (Immediate) - DSCN 12/2008 Data Standards: Quarterly Monitoring: Cancelled Operations Data Set (QMCO)
Release: May 2008
- CR502 (Immediate) - DSCN 10/2008 Data Standards: National Workforce Data Definitions (v2.0)
- CR910 (1 April 2008) - DSCN 08/2008 Data Standards: National Direct Access Audiology Patient Tracking List (PTL) and Waiting Times (WT) data sets
- CR900 (Immediate) - DSCN 07/2008 Data Standards: Inter-Provider Transfer Administrative Minimum Data Set
- CR934 (1 April 2008) - DSCN 06/2008 Data Standards: Mental Health Minimum Data Set (version 3.0)
- CR935 (Immediate) - DSCN 05/2008 Data Standards: 18 Weeks Rules Suite
- CR925 (1 September 2008) - DSCN 04/2008 Genitourinary Medicine Clinic Activity Data Set Change to an Information Standard
- CR942 (1 June 2008) - DSCN 03/2008 General Practice and General Medical Practitioner (GMP) - changes resulting from the introduction of the General Medical Services (GMS) Contract
Release: February 2008
- CR812 (Immediate) - DSCN 01/2008 Central Return: Diagnostics Waiting Times Census Data Set
- CR881 (31 December 2007) - DSCN 42/2007 Central Return: Referral To Treatment Summary Patient Tracking List
- CR904 (Immediate) - DSCN 41/2007 Data Standards: Admission Intended Procedure Update
- CR824 (1 February 2008) - DSCN 39/2007 Data Standards: 48 Hour Genitourinary Medicine Access Monthly Monitoring (GUMAMM)
Release: November 2007
- CR919 (Immediate) - DSCN 38/2007 Data Standards: Mental Health Minimum Data Set Schema
- CR814 (1 April 2008) - DSCN 37/2007 Data Standards: Introduction of Mental Health Minimum Data Set version 2.1
- CR930 (31 December 2007) - DSCN 35/2007 Data Standards: A correction to the version 6 Commissioning Data Set schema
- CR834 (Immediate) - DSCN 34/2007 Data Standards: Referral Request Received Date
- CR875 (Immediate) - DSCN 33/2007 Data Standards: National Administrative Codes Service: Introduction of codes for the new Pan SHAs
- CR880 (Immediate) - DSCN 29/2007 Data Standards: Amendments to Doctor Index Number (DIN) Description
Release: August 2007
- CR845 (Immediate) - DSCN 28/2007 Data Standards: Treatment Function Code (Referral to Treatment Period)
- CR831 (1 October 2007) - DSCN 27/2007 Data Standards: Update to Commissioning Data Set XML Schema v5
- CR825 (1 October 2007) - DSCN 16/2007 Data Standards: Source of Referral for Outpatients (18 Weeks)
Release: June 2007
- CR799 (31 December 2007) - DSCN 18/2007 Data Standards: Introduction of Commissioning Data Set Version 6
- CR833 (Immediate) - DSCN 17/2007 Data Standards: Introduction of Commissioning Data Set validation table
- CR801 (Immediate) - DSCN 15/2007 Data Standards: Cover of Vaccination Evaluated Rapidly (COVER) Return
Release: May 2007
- CR800 (31 December 2007) - DSCN 14/2007 Commissioning Data Set Schema Version 6-0
- CR856 (1 October 2007) - DSCN 13/2007 Data Standards: Discharge Ready Date
- CR869 (Immediate) - DSCN 12/2007 Data Standards: Update to Clinical Coding Introduction
- CR827 (1 October 2007) - DSCN 09/2007 Data Standards: Earliest Reasonable Offer Date
- CR817 (1 October 2007) - DSCN 08/2007 Data Standards: Introduction of Age into Commissioning Data Sets
- CR849 (May 2007) - DSCN 07/2007 National Administrative Codes Service: Introduction of new identification codes for Dental Consultants
- CR822 (Immediate) - DSCN 06/2007 Data Standards: Update to Organisation Codes
- CR850 (Immediate) - DSCN 05/2007 National Administrative Codes Service: Amendments to Default Codes
- CR786 (1 April 2007) - DSCN 04/2007 Quarterly Monitoring Accident and Emergency Services (QMAE) Central Return
Release: February 2007
- CR811 (Immediate) - DSCN 03/2007 Diagnostic Waiting Times and Activity
- CR826 (1 October 2007) - DSCN 02/2007 Extension of Treatment Function to Support the Measurement of 18 Week Referral to Treatment Periods
- CR813 (1 April 2007) - DSCN 01/2007 Paediatric Critical Care Minimum Data Set
- CR768 (1 January 2007) - DSCN 18/2006 Changes to the NHS Data Dictionary to support the measurement of 18 week referral to treatment periods
- CR798 (6 November 2006) - DSCN 19/2006 Commissioning Data Set (CDS) Version 5 XML Message Schema
- CR776 (1 October 2006) - DSCN 05/2006 Data Standards: Accident and Emergency Enhancements to Investigation and Treatment Codes
Release: September 2006
- CR795 (31 October 2006) - DSCN 22/2006 Organisation Codes / Organisation Site Codes
- CR792 (1 April 2007) - DSCN 15/2006 Neonatal Critical Care
- CR719 (1 April 2006) - DSCN 09/2006 Measuring and Recording of Waiting Times
- CR791 (1 April 2007) - DSCN 13/2006 Priority Type
- CR774 (1 September 2006) - DSCN 12/2006 Person Marital Status
Release: May 2006
- CR764 (1 April 2006) - DSCN 08/2006 Diagnostics waiting times and activity
- Correction to menu structure to include Critical Care Minimum Data Set
Release: April 2006
- CR608 (1 October 2006) - DSCN 07/2006 Introduction of Commissioning Data Set Version 5 and its associated XML schema into the NHS Data Dictionary.
- CR756 (1 September 2005) - DSCN 19/2005 PbR Commissioning for Out of Area Treatments (OATs) and Charge-Exempt Overseas Visitors
- CR724 (1 April 2006) - DSCN 13/2005 Critical Care Minimum Data Set
- CR754 (1 April 2006) - DSCN 17/2005 Treatment Function and Main Specialty Code Revisions
- CR763 (1 April 2006) - DSCN 20/2005 New Treatment Functions for therapy services and anticoagulant service
- CR767 (Immediate) - DSCN 02/2006 Referral Request Received Date
- CR690 (1 September 2005) - DSCN 16/2005 Marital Status
Release: August 2005
- CR555 (1 April 2005) - DSCN 11/2005 Data Standards: COVER - Hepatitis B immunisation for babies
- CR715 (Immediate) - DSCN 10/2005 Data Standards: Treatment Function Codes - correction and clarification of names and descriptions
- CR706 (1 April 2005) - DSCN 09/2005 Data Standards: Cancer Registration Data Set
- CR691 (1 July 2005) - DSCN 06/2005 Data Standards: NSCAG Commissioner Code
Change to Supporting Information: Changed Description
Background:
XML Schemas and Release Notes can be downloaded from the Technology Reference Data Update Distribution Service (TRUD).
In order to access the XML Schemas and Release Notes on the Technology Reference Data Update Distribution Service (TRUD), users will be required to:
- Create a TRUD account at: TRUD Welcome to the Technology Reference data Update Distribution site (if an account does not currently exist. This only has to be done once to access any XML Schema)
- Log into TRUD at: TRUD Log in
- Access NHS Data Model and Dictionary: DD XML Schemas and subscribe to the XML Schema to be downloaded
- Accept the licence and request the subscription (an email will be sent immediately to confirm that the request has been accepted and the files can be downloaded, which avoids any delays)
- Once the "Subscription accepted" email has been received, download the zip file from NHS Data Model and Dictionary: DD XML Schemas.
Once an XML Schema has been added to TRUD, users who have subscribed to that item will be automatically notified by email of any updates to that area, for example, new versions, retirements etc.
XML Schema Download:
XML Schemas and Release Notes for the following Data Sets in the NHS Data Model and Dictionary can be downloaded from the Technology Reference Data Update Distribution Service (TRUD) at: NHS Data Model and Dictionary: DD XML Schemas.
- HIV and AIDS Reporting Data Set (HARS)
- Information Sharing to Tackle Violence Minimum Data Set (ISTVDS)
- Maternity Services Data Set (MSDS)
NHS Health Checks Data Set(NHSHC- NHS Health Checks Data Set (NHSHC)
- Systemic Anti-Cancer Therapy Data Set (SACT)
For supplementary information on the XML Schema Publication and Download, see the NHS Data Model and Dictionary website.
Change to Class: Changed Attributes
A and E ATTENDANCE CATEGORY | ||
A and E INITIAL ASSESSMENT TRIAGE CATEGORY | ||
A and E STREAM | ||
ACCIDENT AND EMERGENCY ARRIVAL MODE | ||
ACCIDENT AND EMERGENCY ATTENDANCE DISPOSAL | ||
ANTIRETROVIRAL THERAPY HOME DELIVERY INDICATOR | ||
ANTIRETROVIRAL THERAPY REGIMEN GROUP CODE | ||
BRIEF INTERVENTION PROVIDED INDICATOR | ||
BRIEF INTERVENTION TYPE FOR NHS HEALTH CHECK | ||
CARE CONTACT CANCELLATION REASON | ||
CARE CONTACT SUBJECT | ||
CARE CONTACT TYPE | ||
CHILD DIFFICULT TO TEST REASON | ||
CLINICAL NURSE SPECIALIST INDICATION CODE | ||
CLINIC ATTENDANCE PURPOSE CODE FOR HIV | ||
COLPOSCOPY PRIME PROCEDURE TYPE | ||
CONSULTATION MEDIUM USED | ||
CONSULTATION TYPE | ||
CONTRACEPTIVE SERVICE TYPE | ||
DECISION TO UNDERTAKE FURTHER ASSESSMENT INDICATOR | ||
DIETARY ADVICE REASON CODE | ||
EMPLOYMENT SUPPORT SUITABILITY INDICATOR | ||
FACE TO FACE COMMUNICATION MODE | ||
FEMALE GENITAL MUTILATION IDENTIFICATION METHOD CODE | ||
FIRST ANTIRETROVIRAL THERAPY IN THE UNITED KINGDOM INDICATOR | ||
FIRST ATTENDANCE | ||
FURTHER ASSESSMENT TYPE FOR NHS HEALTH CHECK | ||
HOLISTIC NEEDS ASSESSMENT POINT OF PATHWAY FOR CANCER | ||
INFORMATION AND ADVICE PROVIDED INDICATOR | ||
INFORMATION AND ADVICE TYPE PROVIDED FOR FEMALE GENITAL MUTILATION | ||
INFORMATION AND ADVICE TYPE PROVIDED FOR NHS HEALTH CHECK | ||
INITIAL CONTACT INDICATOR | ||
INITIAL DIAGNOSIS CARE SETTING FOR HIV | ||
MEDICAL STAFF TYPE SEEING PATIENT | ||
METASTATIC STATUS | ||
MULTIPROFESSIONAL OR MULTIDISCIPLINARY INDICATION CODE | ||
NEW HIV DIAGNOSIS IN UNITED KINGDOM INDICATOR | ||
OUTCOME OF ATTENDANCE | ||
PATIENT EXPOSURE TO HIV | ||
PATIENT HIV CARE STATUS | ||
PATIENT TRIAL STATUS FOR CANCER | ||
POST AND/OR PRE EXPOSURE PROPHYLAXIS CODE | ||
POSTNATAL CARE INDICATOR | ||
PREGNANCY INDICATOR FOR HIV | ||
PSYCHIATRIC CARE INDICATOR FOR HIV | ||
SETTLED ACCOMMODATION INDICATOR | ||
SIGNPOSTING TO SERVICE INDICATOR | ||
SIGNPOSTING TO SERVICE TYPE FOR NHS HEALTH CHECK | ||
SKIN TO SKIN CONTACT INDICATOR | ||
SOCIAL WORKER CARE INDICATOR FOR HIV | ||
STATUTORY ASSESSMENT TYPE | ||
SUBJECTIVE GLOBAL ASSESSMENT | ||
THERAPY TYPE FOR IMPROVING ACCESS TO PSYCHOLOGICAL THERAPIES | ||
TWO YEAR NEONATAL OUTCOMES ASSESSMENT NOT CARRIED OUT REASON | ||
Change to Attribute: Changed Description
The reason that a PATIENT was referred to a Community Health Service.
National Codes:
001 | Accident/Trauma |
002 | Alopecia |
003 | Antenatal Care |
004 | Bereavement |
005 | Bladder Care |
006 | Blood Pressure |
007 | Bowel Problems |
008 | Cancer |
009 | Cardiac Conditions |
010 | Catheter Problems |
011 | Cerebral Palsy |
012 | Cleft Palate |
013 | Cognitive Problems |
014 | Colostomy Care |
015 | Continence Problems |
016 | Contraception and Sexual Health (Retired 01 September 2015) |
017 | Developmental Problems |
018 | Diabetes |
019 | Diarrhoea and Vomiting |
020 | Dizziness/Balance Problems |
021 | Downs Syndrome |
022 | Deep Vein Thrombosis |
023 | Ear Infections/Problems |
024 | Eating Disorder |
025 | Emotional/Behavioural Problems |
026 | End of Life Support |
027 | Epilepsy |
028 | Equipment Provision |
029 | Eustachian Tube Dysfunction |
030 | Falls Risk |
031 | Family Support |
032 | Feeding/Swallowing Problems |
033 | Foot Care/Problems |
034 | Head Injury |
035 | Hearing Problems/Loss |
036 | Immunisation |
037 | Laryngectomy |
038 | Leg Ulcer |
039 | Looked After Children |
040 | Low Muscle Tone |
041 | Lymphoedema Management |
042 | Mobility Problems |
043 | Musculoskeletal Problems |
044 | Neurological Problems |
045 | Healthy Child Pathway |
046 | Nutrition and Dietetics |
047 | Ophthalmic Problems |
048 | Over 75 Assessment |
049 | Pain/Symptom Control |
050 | Parkinsons Disease |
051 | Personal Hygiene |
052 | Post Operative Care |
053 | Pressure Ulcer |
054 | Problems with Activities of Daily Living |
055 | Psychological Conditions |
056 | Rehabilitation |
057 | Respiratory Conditions |
058 | Safeguarding |
059 | Skin Problems |
060 | Sleep Problems |
061 | Smoking Cessation |
062 | Speech and Language Problems |
063 | Stoma Care |
064 | Structural/Functional Impairment |
065 | Substance Misuse |
066 | Trismus/Restricted Mouth Opening |
067 | Tuberculosis |
068 | Vascular Problems |
069 | Vomiting/Nausea |
070 | Wound Care |
071 | Multiple Complex Communication Difficulties |
072 | Dental Care/Problems |
073 | Haematology/Phlebotomy |
074 | Chronic Fatigue Syndrome/Myalgic Encephalopathy |
075 | Chronic Allergy/Immunological Problem |
076 | Metabolic/Endocrine Disorders |
077 | Renal Problems |
078 | Minor Surgery |
079 | Gastrostomy Management/Care |
080 | Care of the Next Infant (CONI) Pathway |
081 | Failure to Thrive |
082 | Maternal Mood Problems |
083 | Complex Social Factors (as defined by the National Institute for Health and Care Excellence guidance) |
084 | Condition(s) Requiring Respite Care |
085 | Other Congenital Conditions |
086 | Blood Disorders |
087 | Genetic Disorders |
088 | Neonatal Abstinence Syndrome |
Note: This list is not in alphabetical order.
Change to Data Element: Changed Description
Format/Length: | an1 |
National Codes: | See PERSON GENDER CODE |
Default Codes: |
Notes:
PERSON GENDER CODE CURRENT is the same as attribute PERSON GENDER CODE where the PERSON GENDER TYPE is National Code 'Person Gender Current'.
PERSON GENDER CODE CURRENT is a PERSON's gender currently.
PERSON GENDER CODE CURRENT is used by the Secondary Uses Service to derive the Healthcare Resource Group 4. Failure to correctly populate this data element is likely to result in an incorrect Healthcare Resource Group, usually associated with lower levels of healthcare resource.
For further information, please refer to the Secondary Uses Service Guidance page.
PERSON GENDER CODE CURRENT will be replaced with PERSON STATED GENDER CODE or PERSON PHENOTYPIC SEX, which is the most recent approved national information standard to describe the required definition.<
