| Type: | Patch |
| Reference: | 1643 |
| Version No: | 1.0 |
| Subject: | April 2018 Release Patch |
| Effective Date: | Immediate |
| Reason for Change: | Patch |
| Publication Date: | 24 April 2018 |
Background:
This patch updates the NHS Data Model and Dictionary in preparation for the April 2018 Release and includes:
- What's New amended to include Change Requests incorporated since the last version of the NHS Data Model and Dictionary was published
- Missing hyperlinks added
- Spelling mistakes corrected
- Website links updated
- HTML format corrected.
To view a demonstration on "How to Read an NHS Data Model and Dictionary Change Request", visit the NHS Data Model and Dictionary help pages at: http://www.datadictionary.nhs.uk/Flash_Files/changerequest.htm.
Note: if the web page does not open, please copy the link and paste into the web browser.
Summary of changes:
| Date: | 24 April 2018 |
| Sponsor: | Nicholas Oughtibridge BSc FBCS CITP, Head of Information Standards, NHS Digital |
Note: New text is shown with a blue background. Deleted text is crossed out. Retired text is shown in grey. Within the Diagrams deleted classes and relationships are red, changed items are blue and new items are green.
Click here for a printer friendly view of this page.
Change to Supporting Information: Changed Description
Following the issue of DSCN 07/2004 'Data Standards: Meta Model', the NHS Data Model and Dictionary was changed to reflect and be based upon a more generic logical data model which better supports the strategic way forward. This NHS Data Model and Dictionary was published as the NHS Data Model and Dictionary Version 3.
There was extensive quality assurance of Version 3 including involvement of the Data Definition Group. All Version 3 contents were cross mapped and checked to ensure consistency with the Version 2 contents but the underlying structure was genericised. No changes were made to NHS Business Definitions. Version 3 superseded Version 2 on 1st May 2005.
The NHS Data Dictionary Version 2 has been frozen and made available for archive information purposes only and has been watermarked accordingly.The NHS Data Dictionary Version 2 has been frozen and made available for archive information purposes only and has been watermarked accordingly.
Summary of main changes and enhancements incorporated within Version 3
- Introduction of the capability of holding Retired Items
- Introduction of NHS Business Definitions, which allow specific business areas to be defined in a more flexible manner
- New ‘All Items Index’ which lists all the contents held within the NHS Data Model and Dictionary
- Reduction in the number of data model diagrams making them more comprehensible
- Introduction of Domains, which are conceptual logical modelling objects which identify the logical format, length and value set attributable to one or more attribute(s)
- 'Where Used' list expanded to include a description of usage column
- Creation of a separate Meta Model area within the publication
The introduction of Version 3 had no impact on current information standards or system suppliers.
About the Generic Model
Version 3 introduced a new Generic Model which is 'PERSON based' rather than 'ORGANISATION based'. The model has been developed around generic 'CARE ACTIVITIES' for a PATIENT, with each event transaction being recorded.
The Generic Model supports all the messages, data sets and central returns which the model supported but the underlying structure has been genericised. This involved grouping many of the old classes into generic classes like ACTIVITY GROUP. However, none of the detail was lost and most of the old class definitions can be found under 'NHS Business Definitions'. The number of diagrams has been greatly reduced and they now describe coherent areas of the model which is a far more useful approach for data modellers.
The model is aimed at enabling all 'CARE ACTIVITIES' related to the same condition for the same PATIENT to be recorded and linked across ORGANISATIONS. The different states of the same 'CARE ACTIVITY' are recorded as event transactions e.g. requested, intended, scheduled, provided, cancelled, etc. These different state events also drive the scheduling and capacity planning of resources (people, equipment, facilities, etc.) to deliver the care.
Although this may seem complicated, it is necessary both to form a coherent logical model and to relate physical information such as that which flows on the Data Sets to the logical model. Every physical item should be represented logically in the NHS Data Model and Dictionary. However, the scope of the logical model is greater than the physical information it holds and therefore not all logical information has a physical existence.
Contact us for more information: information.standards@nhs.net.
Change to Supporting Information: Changed Description
|
The "All Items Index" lists all the items in the NHS Data Model and Dictionary in alphabetical order. All items are coloured coded:
There is a link “To top” on each page which takes you back to the top of the "All Items Index" page. What would you like to do next?
|
Change to Supporting Information: Changed Description
|
An Attribute is the detailed information that describes a Class, for example, NHS NUMBER is an Attribute of the Class PATIENT. Each Attribute:
The following information is available on an Attribute:
What would you like to do next?
|
Change to Supporting Information: Changed status to Retired, Name, Description
The Children's Global Assessment Scale (CGAS) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
It is a global rating of functioning aimed at children and young people aged 6-17 years. The child or young person is assessed against different levels of functioning from 0 "Needs constant supervision" to 100 "Superior functioning in all areas".The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
Ratings can be at 10- increment points or as an actual score (e.g. 53).Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
The following score ranges are defined:
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Children's Global Assessment Scale
- Changed Name from Data_Dictionary.NHS_Business_Definitions.C.Children's_Global_Assessment_Scale to Retired.Data_Dictionary.NHS_Business_Definitions.C.Children's_Global_Assessment_Scale
- Changed Description
Change to Supporting Information: Changed Description
|
Classes, Attributes and Relationships are components which together define the NHS Data Model. For further information, see Data Modelling. A Class is something that you want to describe and the Attributes define the detail for the Class. For example, the APPOINTMENT Class in the NHS Data Model describes an arrangement for a PATIENT to be seen by a CARE PROFESSIONAL. Each Class:
The following information is available on a Class:
What would you like to do next?
|
Change to Supporting Information: Changed Description
The Commissioning Data Sets have notation to identify the business and/or processing rules which apply to individual Data Elements. This notation appears in the Rules column of the Commissioning Data Sets details page.
Population Validation
All Data Elements are subject to length validation. Some Data Elements are also subject to format and content validation against a list of permitted values defined in the NHS Data Model and Dictionary. The value lists are held on the Attribute which the Data Element is based on, plus default codes which are held on the Data Element itself.
| RULE | POPULATION VALIDATION |
| F | The format is validated, for example the format of a DATE must comply with the XML standard. |
| V | The Data Element is validated against an explicit list of permitted values as defined in the NHS Data Model and Dictionary. |
Business Rules
Some Data Elements are subject to additional Business Rules as indicated below:
- Prefix H = Healthcare Resource Group Business Rules.
- Prefix I = CDS-XML Schema anomalies and issues.
- Prefix N = NHS Data Standards and Policy Rules
- Prefix S = Secondary Uses Service Business Rules
| PREFIX | BUSINESS RULES: H - Healthcare Resource Group Business Rules |
| H4 | This Data Element is used by the Secondary Uses Service to derive the Healthcare Resource Group 4. Failure to correctly populate this data element is likely to result in an incorrect Healthcare Resource Group, usually associated with lower levels of healthcare resource. For further information, please refer to the NHS Digital website at: Payment by Results Guidance. |
| PREFIX | BUSINESS RULES: I - CDS-XML Schema Anomalies and Issues |
| I1 | This is a known schema anomaly and has been registered for future resolution. |
| I2 | See the specifications in the NHS Data Model and Dictionary for the specific format characteristics of this Data Element. |
| I3 | There is no national requirement to flow Healthcare Resource Group 4 (HRG4) through the Commissioning Data Sets, see DSCN 17/2008. |
| PREFIX | BUSINESS RULES: N - NHS Data Standards and Policy Rules |
| N1 | Psychiatric PATIENTS only. |
| N2 | Not defined or approved by the Data Coordination Board or its predecessors the Standardisation Committee for Care Information and Information Standards Board for Health and Social Care. |
| N3 | The definition and value list for this data is under review. |
| N4 | Up to 20 codes per daily activity occurrence may be recorded. |
| N5 | This data should only flow in Commissioning Data Set version 6-1 for PATIENTS detained under the Mental Health Act prior to the Mental Health Act 2007 (Retired June 2015). |
| N6 | This data should only flow in Commissioning Data Set version 6-2 for PATIENTS detained under the Mental Health Act 2007. |
| N7 | From Commissioning Data Set version 6-0 onwards, the use of the DETAINED AND (OR) LONG TERM PSYCHIATRIC CENSUS DATE in the location group is optional as it must be carried in the Episode Characteristics. |
| PREFIX | BUSINESS RULES: S - Secondary Uses Service Business Rules |
| S1 | This mandatory Commissioning Data Set date is used as the originating date to determine the mandatory CDS ACTIVITY DATE. |
| S2 | The Secondary Uses Service DOES NOT support the use of the CDS TEST INDICATOR. Therefore this Data Element must not be used (Retired June 2015). |
| S3 | See Security Issues and Patient Confidentiality, for further information. |
| S4 | Used to ensure the correct sequencing of multiple and/or subsequent Commissioning Data Set submissions. |
| S5 | These ORGANISATION CODES must be present and registered with the Secondary Uses Service. The Commissioning Data Set Schema does not validate the content value of this data |
| S6 | All CDS REPORT PERIOD START DATES and CDS REPORT PERIOD END DATES must be consistent in all Commissioning Data Set records contained in a BULK Interchange submission. The CDS REPORT PERIOD START DATE must be on or before the CDS REPORT PERIOD END DATE. The CDS ACTIVITY DATE is a mandatory data element and must fall within the period defined. See the Commissioning Data Set Submission Protocol. |
| S7 | See the Commissioning Data Set Addressing Grid. |
| S8 | These Data Elements are required for correct processing by the Secondary Uses Service. If omitted, the Secondary Uses Service will reject the Commissioning Data Set data. |
| S9 | The CDS UNIQUE IDENTIFIER is a mandatory data item when using the Net Change Protocol. When using the Bulk Update Protocol this data item is optional but it is strongly advised that where it can be correctly generated and maintained it should be used. See the Commissioning Data Set Submission Protocol. |
| S10 | For CDS V6-2 Type 170 - Admitted Patient Care - Detained and or Long Term Psychiatric Census Commissioning Data Set, the CDS ACTIVITY DATE contains the CDS CENSUS DATE which is also the DETAINED AND (OR) LONG TERM PSYCHIATRIC CENSUS DATE. |
| S11 | For the following CDS Types, the CDS ACTIVITY DATE must contain the Date of the Elective Admission List Census which is usually the end of the Period being reported: CDS V6-2 Type 030 - Elective Admission List - End of Period Census (Standard) Commissioning Data Set CDS V6-2 Type 040 - Elective Admission List - End Of Period Census (Old) Commissioning Data Set CDS V6-2 Type 050 - Elective Admission List - End Of Period Census (New) Commissioning Data Set |
| S12 | These PERSON BIRTH DATE Data Elements must use DATES between 01/01/1880 and 31/12/2999 in order to pass validation |
| S13 | Data Elements reporting a DATE (which is not a PERSON BIRTH DATE Data Element) must use dates between 01/01/1900 and 31/12/2999 in order to pass validation |
| S14 | For Data Elements reporting a TIME, the hour portion must be between 00 and 23 inclusive in order to pass validation |
Change to Supporting Information: Changed Description
|
A Data Set is a group of Data Elements that are required to support business analysis, for example, data associated with an Accident and Emergency Attendance is transmitted in the CDS V6-2 Type 010 - Accident and Emergency Commissioning Data Set. The primary purpose of national data sets is to enable the same health information to be generated across the country independent of the Organisation or system that captures it. Note: The NHS Data Model and Dictionary does not contain all national data collections. Data Sets are grouped together on the front page of the NHS Data Model and Dictionary under Data Collections. A description of each type of data set can be found by hovering over the item name. The Commissioning Data Sets section also contains supplementary information, see the Commissioning Data Sets Help page for further information. Each Data Collection name is in Title Case. Where the name of a:
There are three frames to each Data Set:
What would you like to do next?
|
Change to Supporting Information: Changed Description
A Data Dictionary Change Notice (DDCN) is a notice of a change to the NHS Data Model and Dictionary which is not appropriate for Data Coordination Board publication as an Information Standards Notice, as the change does not relate to an individual standard.
The Data Dictionary Change Notices can be downloaded from: Data Dictionary Change Notices.The Data Dictionary Change Notices can be downloaded from: Data Dictionary Change Notices.
Further information on Data Dictionary Change Notices can be found on the NHS Data Model and Dictionary Service part of the NHS Digital website at: Policies: Data Dictionary Change Notice guidance.
Change to Supporting Information: Changed Description
|
A Data Element is the definition of the information which is usually transmitted in a Data Set. In addition, Data Elements can contain text providing guidance, support, values or other information concerning the Data Element and its usage. Each Data Element:
The following information is available on an Data Element:
What would you like to do next?
|
Change to Supporting Information: Changed Description
|
Classes, Attributes and Relationships are components which together define the NHS Data Model and are a suggested reference point for System Suppliers when developing systems. Note: Data Elements and Data Sets, which define the national information requirements, reference the NHS Data Model components to form part of the wider NHS Data Model and Dictionary.
NHS Data Model The NHS Data Model provides:
What would you like to do next?
|
Change to Supporting Information: Changed Description
|
A number of short demonstrations are available which will take you through each component, step by step, in an easy to understand screen capture including a voice over and readable captions. Please note that the information contained in the demonstrations was correct at the time of publication. If you are not familiar with the NHS Data Model and Dictionary, it is recommended that you proceed through the demonstrations in the following order. The subjects covered are: At the end of each demonstration, you can choose where you want to go next, you can either:
Once you have completed the demonstrations, there are two quizzes to check your understanding of the help pages and the navigation options: The content of these demonstrations is for training purposes only and therefore may not match the current content of the NHS Data Model and Dictionary. Please refer to the Main Menu for the latest version of the NHS Data Model and Dictionary. There are also presentations for: How to use the Demonstrations
Please note:
What would you like to do next?
|
Change to Supporting Information: Changed Description
|
The NHS Data Model and Dictionary has a number of diagrams which represent specific parts of the NHS Data Model. The diagrams show:
There are three frames to each Diagram:
What would you like to do next?
|
Change to Supporting Information: Changed status to Retired, Name, Description
The Family Assessment Device (General Functioning Subscale) (FAD) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
The General Functioning Subscale of the Family Assessment Device is a 12-item questionnaire which constitutes part of the larger Family Assessment Device. The General Functioning Subscale has been widely used as a brief method of assessing overall family functioning. It is designed to be completed by family members over 12 years of age.The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
Each item is rated from 1 (Strongly Agree) to 4 (Strongly Disagree) with negatively worded items being reverse scored and missing values rated as 99. A total score can be calculated from the valid summed item scores and divided by 12.Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Family Assessment Device (General Functioning Subscale)
- Changed Name from Data_Dictionary.NHS_Business_Definitions.F.Family_Assessment_Device_(General_Functioning_Subscale) to Retired.Data_Dictionary.NHS_Business_Definitions.F.Family_Assessment_Device_(General_Functioning_Subscale)
- Changed Description
Change to Supporting Information: Changed Description
Welcome to the NHS Data Model and Dictionary Help Pages
Please note that the icons are not hyperlinks. |
ITEM NAME | DESCRIPTION | NAVIGATION | HELP | DEMONSTRATIONS |
| About Us | The NHS Data Model and Dictionary is maintained by the NHS Data Model and Dictionary Service | None | About Us Help | None |
| All Item Index (A-Z) | The NHS Data Model and Dictionary has an All Items Index which lists all the items in the dictionary in alphabetical order | All Items Index (A-Z) | All Items Index Help | All Items Index Demonstration |
| Attributes | An Attribute is the detailed information that describes a Class | Attributes | Attributes Help | Attributes Demonstration |
| Background | The NHS Data Model and Dictionary provides a reference point for approved Information Standards and Collections (including Extractions) within the NHS in England | None | Background | None |
| Classes | A Class is something that you want to describe and the Attributes define the detail for the Class | Classes | Classes Help | Classes Demonstration |
| Commissioning Data Sets | The Commissioning Data Set is the basic structure used for the submission of commissioning data to the Secondary Uses Service | Commissioning Data Sets | Commissioning Data Sets Help | None |
| Data Collections | A Data Collection or Data Set is a group of Data Elements that are required to support business analysis | Data Collections | Data Collections Help | Data Collections Demonstration |
| Data Elements | A Data Element is the definition of the information which usually flows in a Data Set. In addition, they can contain text providing guidance, support, values or other information | Data Elements | Data Elements Help | Data Elements Demonstration |
| Data Modelling Introduction | The NHS Data Model and Dictionary is made up of a number of components | None | Data Modelling Introduction | NHS Data Model and Dictionary Components |
| Demonstrations | A number of short demonstrations are available which will take you through the NHS Data Model and Dictionary components | None | Demonstrations | None |
| Diagrams | The NHS Data Model and Dictionary has a small set of diagrams which represent parts of the NHS Data Model | Diagrams | Diagrams Help | Diagrams Demonstration |
| Help Introduction | The NHS Data Model and Dictionary Help Introduction Page will help direct you to the information you require | None | Help | None |
| Navigation | There are many ways to navigate the NHS Data Model and Dictionary. | None | Navigation | None |
| NHS Business Definitions | Each NHS Business Definition consists of freestanding text which describes an aspect of NHS activity | NHS Business Definitions | NHS Business Definitions Help | NHS Business Definitions Demonstration |
| Related DDCN/DSCN/ISN | The Related DDCN/DSCN/ISN link shows which Data Dictionary Change Notice (DDCN), Data Set Change Notice (DSCN) or Information Standards Notice (ISN) made changes to an item | Main Menu | Related DDCN/DSCN/ISN Help | Related DDCN/DSCN/ISN Demonstration |
| Search | The NHS Data Model and Dictionary has a Quick Search Facility and an Advanced Search Facility | Main Menu and Advanced Search | Search Help | Search Demonstration |
| Supporting Information | Supporting Information provides information to help users understand and use the NHS Data Model and Dictionary | Supporting Information | Supporting Information Help | Supporting Information Demonstration |
| Test Your Knowledge | Test Your Knowledge can be found at the end of each Demonstration to check your understanding of the subject | None | Test Your Knowledge | None |
| What's New | The What's New page shows the Information Standards Notices, Data Set Change Notices and Data Dictionary Change Notices that have been incorporated into each release of the NHS Data Model and Dictionary | What's New | What's New Help | What's New Demonstration |
Please note that the information contained in the demonstrations was correct at the time of publication.
Change to Supporting Information: Changed Description
A Learning Disability (formerly known as a Mental Handicap and referred to as an Intellectual Disability) is a type of DISABILITY.
A Learning Disability usually has a significant impact on a PERSON's life. A PERSON with a Learning Disability finds it harder than others to learn, understand and communicate.
People with Profound and Multiple Learning Disabilities need full-time help with every aspect of their lives, including eating, drinking, washing, dressing and toileting etc.
Learning Disability includes the presence of a significantly reduced ability to understand new or complex information, to learn new skills (impaired intelligence), with
- a reduced ability to cope independently (impaired social functioning)
- which started before adulthood, with a lasting effect on development.
Further information regarding people covered by definition can be found in the document 'Valuing People - A New Strategy for Learning Disability for the 21st Century'.
Although, from a social care perspective, an Intelligence Quotient (IQ) of seventy or less is not sufficient reason for deciding if an individual should be provided with additional health and social care support, the following definition is applied within the Mental Health Services Data Set in the specific circumstance where data providers do not have an explicit data item to capture whether a PATIENT has a Learning Disability.
Someone is considered to have a Learning Disability when they function at a level of intellectual ability which is significantly lower than their chronological age. This is usually considered to be equivalent to having an IQ of seventy or less:
- Mild Learning Disability (roughly equivalent to an IQ of fifty to seventy) is comparable to the educational term 'Moderate Learning Difficulty'. It is usually caused by a combination of restricted learning and social opportunities plus a high rate of low to average intellectual ability and Learning Disability in close relatives.
- Moderate-to-profound Learning Disability (roughly equivalent to an IQ below fifty) is comparable to the educational term 'Severe Learning Difficulty'. It usually has a specific biological cause.
Note: A Learning Difficulty is a type of Special Education Need which affects areas of learning, such as reading, writing, spelling, mathematics etc.
Further information on Learning Disabilities, can be found on the internet, for example:
Change to Supporting Information: Changed status to Retired, Name, Description
The Mood And Feelings Questionnaire (MFQ) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
The Mood And Feelings Questionnaire is a self-report measure used to screen for depression.The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
For further information on the Mood And Feelings Questionnaire, see the NICE guidelines.Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Mood And Feelings Questionnaire
- Changed Name from Data_Dictionary.NHS_Business_Definitions.M.Mood_And_Feelings_Questionnaire to Retired.Data_Dictionary.NHS_Business_Definitions.M.Mood_And_Feelings_Questionnaire
- Changed Description
Change to Supporting Information: Changed Description
|
The text for each NHS Business Definition starts by identifying which Class is used and is followed by a description of the item. Each NHS Business Definition name is distinguished from Classes, Attributes and Data Elements by appearing in Title Case rather than UPPERCASE (see the example below) and where the name in text in Blue, it indicates that it is a hyperlink and if clicked on will display the definition for that NHS Business Definition. An example of an NHS Business Definition is a Hospital Provider Spell, which is related to the Class ACTIVITY GROUP. The following information is available on an NHS Business Definition:
What would you like to do next?
|
Change to Supporting Information: Changed status to Retired, Name, Description
The Paddington Complexity Scale (PCS) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
The Paddington Complexity Scale is a 13-item, clinician-rated scale which records:The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
case complexityduration and severity of main problemsinvolvement in education and looked-after systems and the number of different agencies involved
Each variable is scored on presence/absence or severity if present, and a total score is calculated.Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Paddington Complexity Scale
- Changed Name from Data_Dictionary.NHS_Business_Definitions.P.Paddington Complexity Scale to Retired.Data_Dictionary.NHS_Business_Definitions.P.Paddington Complexity Scale
- Changed Description
Change to Supporting Information: Changed status to Retired, Name, Description
The Parenting Daily Hassles (PDH) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
The aim of Parenting Daily Hassles is to assess the frequency and intensity/impact of 20 experiences that can be a 'hassle' to parents.The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
The caregiver is asked to score each of the potential 'hassles' in two different ways for frequency and intensity. The frequency of each type of happening provides an 'objective' marker of how often it occurs. The intensity or impact score indicates the caregivers 'subjective' appraisal of how much those events affect or 'hassle' them.Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
The time frame for this scale can be varied according to the focus of the assessment. For example, if a family is thought to have been under particular pressure in the last 2 months, the parent can be asked to consider how matters have been during that period. However, if it is intended to assess progress, the same time frame should be used on each occasion. Periods of less than one month are probably too short to give a useful picture.
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Parenting Daily Hassles
- Changed Name from Data_Dictionary.NHS_Business_Definitions.P.Parenting_Daily_Hassles to Retired.Data_Dictionary.NHS_Business_Definitions.P.Parenting_Daily_Hassles
- Changed Description
Change to Supporting Information: Changed status to Retired, Name, Description
The Parenting Stress Index (PSI) is a type of ASSESSMENT TOOL.This item has been retired from the NHS Data Model and Dictionary.
The Parenting Stress Index is used to identify parent-child problem areas, and is suitable for parents of children aged 1 month to 12 years. The Parenting Stress Index is designed for the early identification of parenting and family characteristics that fail to promote normal development and functioning in children, children with behavioural and emotional problems, and parents who are at risk of dysfunctional parenting.The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
The Parenting Stress Index consists of 120 items, and yields a Total Stress Score, plus Scale Scores for both parent and child, which pinpoint sources of stress within the family.Access to this version can be obtained by emailing information.standards@nhs.net with "NHS Data Model and Dictionary - Archive Request" in the email subject line.
For further information on the Parenting Stress Index, see the Hogrefe website.
Change to Supporting Information: Changed status to Retired, Name, Description
- Retired Parenting Stress Index
- Changed Name from Data_Dictionary.NHS_Business_Definitions.P.Parenting Stress Index to Retired.Data_Dictionary.NHS_Business_Definitions.P.Parenting Stress Index
- Changed Description
Change to Supporting Information: Changed Description
|
The Related DDCN/DSCN/ISN page shows which Data Dictionary Change Notice (DDCN), Data Set Change Notice (DSCN) or Information Standards Notice (ISN) made changes to an item. The Related DDCN/DSCN/ISN page can be found at the top right hand side under the Quick Search box on every page. What would you like to do next?
|
Change to Supporting Information: Changed Description
|
There are two search facilities in the NHS Data Model and Dictionary:
What would you like to do next?
|
Change to Supporting Information: Changed Description
|
Supporting Information provides additional information to help users understand and use the NHS Data Model and Dictionary. What would you like to do next?
|
Change to Supporting Information: Changed Description
Supporting Information provides information to help users understand and use the NHS Data Model and Dictionary.
Use the links below to access more detailed information: |
| Coding and Classifications: | Organisation Information: |
| NHS Data Model and Dictionary Information: | Contacts / Links: |
| |
Archived Publications |
Change to Supporting Information: Changed Description
- Coding and Classifications
- Clinical Coding
- Main Specialty and Treatment Function Codes
- Organisation Information
- Health and Social Care Organisation Reference Data
- NHS Postcode Directory
- ODS Default Codes
- Organisation Mergers
- NHS Data Model and Dictionary Information
- About Version 3
- Change Request Log
- Disclaimer
- Glossary of Terms
- Meta Model
- Contacts/ Links
- Contact Details
- Published Information Standards Documentation
- NHS Data Model and Dictionary Service Web Pages
- Archived Publications
NHS Data Model and Dictionary Version 2.0- NHS Data Model and Dictionary Version 2.0
Change to Supporting Information: Changed Description
|
A number of short Demonstrations are available which will take you through each component, step by step, in an easy to understand screen capture including a voice over and readable captions. Please note that the information contained in the demonstrations was correct at the time of publication. At the end of each demonstration, you can choose where you want to go next, you can either:
The Test Your Knowledge section provides 3 questions on each of the Demonstrations to check your understanding of the subject: Once you have completed the Demonstrations and Test Your Knowledge, there are two quizzes to check your understanding of the help pages and the navigation options: What would you like to do next?
|
Change to Supporting Information: Changed Name, Description
Information Standards Notices and Data Dictionary Change Notices incorporated into the NHS Data Model and Dictionary:
Release: April 2018
- CR1638 (30 April 2018) - DCB0090 Health and Social Care Organisation Reference Data: Introducing an Application Programming Interface (API)
Release: March 2018
- CR1588 (1 April 2018) - DCB1521 Cancer Outcomes and Services Data Set Version 8
- CR1589 (1 April 2018) - DCB0147 National Cancer Waiting Times Monitoring Data Set Version 2.0
- CR1610 (1 April 2018) - DCB0011 Mental Health Services Data Set Version 3.0
Release: January 2018
CR1633 (Immediate) -DDCN 1633/2017Introduction of Strategic Data Collection Service (SDCS) and Data Services Platform (DSP)- CR1633 (Immediate) - DDCN 1633/2017 Introduction of Strategic Data Collection Service (SDCS) and Data Services Platform (DSP)
Release: November 2017
- CR1623 (Immediate) - DCB0089 Cover of Vaccination Evaluated Rapidly (COVER) Central Return Data Set
Release: October 2017
- CR1619 (1 October 2017) - DCB1067 National Workforce Data Set Version 2.9
- CR1595 (Immediate) - DCB0155 Stop Smoking Services Quarterly Data Set
- CR1572 (Immediate) - DCB2094 Sexual Orientation
- The October 2017 Release updates the NHS Data Model and Dictionary Help Pages and Demonstrations to reflect the new organisation structure.
Release: September 2017
- CR1587 (1 October 2017) - SCCI1069 Community Services Data Set (CSDS) Version 1.0
Release: July 2017
- CR1555 (Immediate) - SCCI1518 Sexual and Reproductive Health Activity Data Set Changes
- CR1606 (Immediate) - SCCI0011 Mental Health Services Data Set Version 2 Corrigendum
Release: June 2017
CR1607 (Immediate) -DDCN 1607/2017Renaming of NHS Commissioning Board Commissioning Region and NHS England Region (Geography)- CR1607 (Immediate) - DDCN 1607/2017 Renaming of NHS Commissioning Board Commissioning Region and NHS England Region (Geography)
Release: April 2017
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 October 2017:
- CR1598 (1 October 2017) - SCCI0092-2062 Commissioning Data Set Type 011 Emergency Care
Release: March 2017
CR1605 (Immediate) -DDCN 1605/2017NHS Number Status Indicator Code- CR1605 (Immediate) - DDCN 1605/2017 NHS Number Status Indicator Code
- CR1564 (01 April 2017) - SCCI1521 Cancer Outcomes and Services Data Set Version 7
- CR1563 (01 April 2017) - SCCI0011 Mental Health Services Data Set Version 2.0
- CR1577 (01 April 2017) - SCCI0084 Introduction of OPCS-4.8
Release: December 2016
Release: November 2016
- CR1442 (01 November 2016) - SCCI1570 Amd 20/2015 HIV and AIDS Reporting Data Set and XML Schema Version 3
Release: October 2016
CR1578 (Immediate) -DDCN 1578/2016Religious or Other Belief System Affiliation Groups SNOMED CT Subset- CR1578 (Immediate) - DDCN 1578/2016 Religious or Other Belief System Affiliation Groups SNOMED CT Subset
Release: September 2016
- CR1545 (Immediate) - SCCI0075 and SCCI0076 Updates to the Neonatal Critical Care and Paediatric Critical Care Minimum Data Sets
Release: August 2016
- CR1532 (Immediate) - SCCI0090 Health and Social Care Organisation Reference Data
CR1583 (Immediate) -DDCN 1583/2016Introduction of NHS DigitalCR1575 (Immediate) -DDCN 1575/2016Introduction of the National Cancer Registration and Analysis Service (NCRAS)CR1570 (Immediate) -DDCN 1570/2016Update to COVER Central Return Data Set- CR1583 (Immediate) - DDCN 1583/2016 Introduction of NHS Digital
- CR1575 (Immediate) - DDCN 1575/2016 Introduction of the National Cancer Registration and Analysis Service (NCRAS)
- CR1570 (Immediate) - DDCN 1570/2016 Update to COVER Central Return Data Set
Release: July 2016
- CR1565 (Immediate) - ISB 1561 Retirement of Diabetes Summary Core Data Set ISB 1561
Release: March 2016
- CR1300 (1 April 2016) - SCCI01477 Updates to the National Cancer Waiting Times Monitoring Data Set and introduction of the XML Schema
- CR1412 (1 April 2016) - SCCI0021 Introduction of the International Classification of Diseases (ICD) 10th Revision 5th Edition
- CR1544 (1 April 2016) - SCCI1111 Radiotherapy Data Set - Change of data flow
- CR1549 (1 April 2016) - SCCII0011 Mental Health Services Data Set Version 1.1
Release: February 2016
- CR1517 (1 January 2016) - SCCI1067 Workforce Data Set Version 2.8
CR1559 (Immediate) -DDCN 1559/2016Lower Layer Super Output Area (Residence) and ONS Local Government Geography Code (Local Authority District)- CR1559 (Immediate) - DDCN 1559/2016 Lower Layer Super Output Area (Residence) and ONS Local Government Geography Code (Local Authority District)
Release: December 2015
- CR1514 (1 January 2016) - SCCI0011 Mental Health Services Data Set
- CR1515 (1 January 2016) - SCCI0011 Retirement of Mental Health Standards
CR1560 (Immediate) -DDCN 1560/2015Retirement of Data Management and Integration Centre- CR1560 (Immediate) - DDCN 1560/2015 Retirement of Data Management and Integration Centre
Release: November 2015
CR1558 (Immediate) -DDCN 1558/2015Children and Young People’s Health Services Data Set and Community Information Data Set Inconsistencies- CR1558 (Immediate) - DDCN 1558/2015 Children and Young People’s Health Services Data Set and Community Information Data Set Inconsistencies
- CR1554 (1 October 2015) - SCCI2026 Corrigendum to CR1494 Female Genital Mutilation Data Set
Release: October 2015
CR1534 (Immediate) -DDCN 1534/2015Retirement of Hospital Episode Statistics Cross Reference Tables- CR1534 (Immediate) - DDCN 1534/2015 Retirement of Hospital Episode Statistics Cross Reference Tables
Release: September 2015
- CR1521 (Immediate) - SCCI1580 Palliative Care Co-ordination: Core content (Formerly End of Life Care)
CR1522 (Immediate) -DDCN 1522/2015Update General Dental Council Registration Number- CR1522 (Immediate) - DDCN 1522/2015 Update General Dental Council Registration Number
- CR1530 (Immediate) - ISB 0158 Retirement of Ambulance Services (KA34) Central Return Data Set
- CR1528 (Immediate) - ISB 1568 Retirement of KO41 (A) Hospital and Community Health Service Complaints and KO41 (B) General Practice (including Dental) Complaints Central Return Forms
- CR1551 (Immediate) - ISB 0133 Retirement of HPV Immunisation Programme Vaccine Monitoring Monthly Minimum Data Set and HPV Immunisation Programme Vaccine Monitoring Annual Minimum Data Set
Release: August 2015
- CR1374 (1 September 2015) - SCCI1510 Community Information Data Set Update
- CR1356 (1 September 2015) - SCCI1069 Children and Young People’s Health Services Data Set Update and XML Schema
CR1529 (Immediate) -DDCN 1529/2015Change to the Mechanism for XML Schema Publication and DownloadCR1543 (Immediate) -DDCN 1543/2015Treatment Function Code: 840 Audiology- CR1529 (Immediate) - DDCN 1529/2015 Change to the Mechanism for XML Schema Publication and Download
- CR1543 (Immediate) - DDCN 1543/2015 Treatment Function Code: 840 Audiology
Release: July 2015
- CR1475 (Immediate) - SCCI1605 Accessible Information
Release: June 2015
- CR1518 (Immediate) - ISB 092 CDS 6-1 Retirement
CR1525 (Immediate) -DDCN 1525/2015Burden Advice and Assessment Service (BAAS)CR1524 (Immediate) -DDCN 1524/2015Updating of Activity Location Type and Source of Admission AttributesCR1505 (Immediate) -DDCN 1505/2015Death Cause Information- CR1525 (Immediate) - DDCN 1525/2015 Burden Advice and Assessment Service (BAAS)
- CR1524 (Immediate) - DDCN 1524/2015 Updating of Activity Location Type and Source of Admission Attributes
- CR1505 (Immediate) - DDCN 1505/2015 Death Cause Information
Release: May 2015
CR1507 (Immediate) -DDCN 1507/2015To add SUS CDS business rule H4 text- CR1507 (Immediate) - DDCN 1507/2015 To add SUS CDS business rule H4 text
Release: April 2015
- CR 1494 and CR 1506 (1 April 2015) - SCCI2026 Amd 12/2014 Female Genital Mutilation Data Set and Retirement of Female Genital Mutilation Prevalence Data Set
CR1513 (27 April 2015) -DDCN 1513/2015Introduction of NHS England Region (Geography)- CR1513 (27 April 2015) - DDCN 1513/2015 Introduction of NHS England Region (Geography)
- CR1509 (1 April 2015) - ISB 1513 Maternity Services Data Set
CR1509 is a corrigendum to CR1355 (1 November 2014) - ISB 1513 Amd 45/2012 Maternity Services Data Set Update and XML Schema published in the October 2014 release
Release: March 2015
- CR1492 (1 April 2015) - SCCI1521 Amd 17/2014 Updates to the Cancer Outcomes and Services Data Set and XML Schema
Release: February 2015
- CR1486 (27 February 2015) - ISB 0090 Amd 9/2014 Organisation Data Service – Health and Justice Organisation Identifiers
Due to a delay in the Organisation Data Service (ODS) February release, the implementation date is now 6 March 2015.
Release: January 2015
- CR1473 (1 January 2015) - ISB 1538 Amd 13/2014 Chlamydia Testing Activity Data Set Update
CR1496 (Immediate) -DDCN 1496/2015Clinical Coding- CR1496 (Immediate) - DDCN 1496/2015 Clinical Coding
Release: December 2014
- CR1396 (31 October 2014) - ISB 1567 Amd 15/2014 National Joint Registry Data Set Version 6
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 October 2015:
- CR1487 (1 October 2015) - ISB 0089 Amd 8/2014 Cover of Vaccination Evaluated Rapidly (COVER) Central Return Data Set
Release: November 2014
- CR1420 (Immediate) - ISB 0139 Amd 29/2013 Genitourinary Medicine Clinic Activity Data Set (GUMCAD) Update
- CR1421 (Immediate) - ISB 1518 Amd 30/2013 Sexual and Reproductive Health Activity Data Set (SRHAD) Update
- CR1422 (Immediate) - ISB 1518 Amd 30/2013 Retirement of Central Return Form KT31 Cross Sector Services
Release: October 2014
- CR1355 (1 November 2014) - ISB 1513 Amd 45/2012 Maternity Services Data Set Update and XML Schema
Release: September 2014
CR1484 (Immediate) -DDCN 1484/2014Female Genital Mutilation SNOMED CT Subsets- CR1484 (Immediate) - DDCN 1484/2014 Female Genital Mutilation SNOMED CT Subsets
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 31 July 2015:
- CR1344 (31 July 2015) - ISB 1594 Amd 31/2012 Information Sharing to Tackle Violence Minimum Data Set
Release: August 2014
- CR1360 (1 September 2014) - ISB 0011 Amd 5/2014 Mental Health and Learning Disabilities Data Set
Release: July 2014
- CR1351 (1 July 2014) - ISB 1520 Amd 02/2013 Improving Access to Psychological Therapies Data Set Version 1.5
CR1482 (Immediate) -DDCN 1482/2014Source of Referral for Mental HealthCR1480 (Immediate) -DDCN 1480/2014Mental Health Care Cluster 9CR1477 (Immediate) -DDCN 1477/2014Payment by Results- CR1482 (Immediate) - DDCN 1482/2014 Source of Referral for Mental Health
- CR1480 (Immediate) - DDCN 1480/2014 Mental Health Care Cluster 9
- CR1477 (Immediate) - DDCN 1477/2014 Payment by Results
- Note: CR1383 (31 December 2014) - ISB 1555 Amd 10/2012 Personal Demographics Service Birth Notification Data Sets
At the Standardisation Committee for Care Information meeting on 28th May 2014, an amendment to the implementation date of the ISB information standard was approved. The implementation date is now 31 December 2014.
- The July 2014 Release updates the NHS Data Model and Dictionary Help Pages to reflect the new organisation structure.
Release: June 2014
CR1465 (Immediate) -DDCN 1465/2014Primary Care Trusts and NHS TrustsCR1461 (Immediate) -DDCN 1461/2014New Standardisation Committee for Care Information (SCCI) Process- CR1465 (Immediate) - DDCN 1465/2014 Primary Care Trusts and NHS Trusts
- CR1461 (Immediate) - DDCN 1461/2014 New Standardisation Committee for Care Information (SCCI) Process
- CR1383 (30 June 2014) - ISB 1555 Amd 10/2012 Personal Demographics Service Birth Notification Data Sets
Release: May 2014
- CR1353 (1 June 2014) - ISB 1067 Amd 22/2013 Workforce Data Set Version 2.7
Release: April 2014
- CR1449 (Immediate) - ISB 1610 Amd 01/2014 Female Genital Mutilation Prevalence Data Set
Release: March 2014
- CR1388 (1 April 2014) - ISB 1521 Amd 23/2013 Updates to the Cancer Outcomes and Services Data Set and XML Schema
- CR1370 (1 April 2014) - ISB 1533 Amd 24/2013 Updates to the Systemic Anti-Cancer Therapy Data Set and XML Schema
- CR1322 (1 April 2014) - ISB 0111 Amd 26/2012 Changes to the Radiotherapy Data Set
- CR1387 (1 April 2014) - ISB 0084 Amd 10/2013 Introduction of OPCS-4.7
- CR1376 (1 April 2014) - ISB 1607 Amd 26/2013 Emergency Care Weekly Situation Report Data Set
CR1433 (Immediate) -DDCN 1433/2014Data Services for CommissionersCR1467 (1 April 2014) -DDCN 1467/2014Retirement of StandardsCR1464 (1 April 2014) -DDCN 1464/2014Retirement of Standards - Domains and DiagramsCR1458 (1 April 2014) -DDCN 1458/2014Retirement of Standards - DSCNs - 11/97/P05, 12/97/P06, 15/97/P09, 18/97/P12, 22/96/P19, 32/96/P27, 49/97/P35, 62/95/P51, 07/2007, 08/2009, 17/92, 20/2001, 22/2006 and 38/2002CR1444 (1 April 2014) -DDCN 1444/2014Retirement of StandardsCR1436 (1 April 2014) -DDCN 1436/2014Retirement of StandardsCR1435 (1 April 2014) -DDCN 1435/2014Retirement of Standards - DSCNs 22/95/P21, 20/91, 21/93, 40/95/P34, 09/94/P04, 93/95/P76, 23/94/A04, 8/92 and 17/93CR1432 (1 April 2014) -DDCN 1432/2014Retirement of Standards - DSCN 3/92, DSCN 12/96/P11, DSCN 50/94/P36, DSCN 66/96/W09 and DSCN 16/93CR1429 (1 April 2014) -DDCN 1429/2014Retirement of Standards - DSCN 07/96/P06CR1425 (1 April 2014) -DDCN 1425/2014Retirement of StandardsCR1423 (1 April 2014) -DDCN 1423/2014Retirement of Standards - DSCNs 37/98/A09, 14/97/P08, 12/2002, 37/2003, 14/2004 and 27/2001CR1419 (1 April 2014) -DDCN 1419/2014Retirement of Standards - DSCNs 39/98/A11, 09/99/P06, 11/99/P07, 13/2003, 38/2001, 22/2001, 19/98/A02, 40/96/P34, 29/94/P19, 49/94/P35, 34/95/P29, 53/96/P44 and 96/95/P79CR1418 (1 April 2014) -DDCN 1418/2014Retirement of StandardsCR1417 (1 April 2014) -DDCN 1417/2014Retirement of Standards - DSCNs 13/95/P12, 44/2001, 29/2004, 18/98/W02 and 24/98/F01CR1416 (1 April 2014) -DDCN 1416/2014Retirement of Standards - KC64 - DSCNs 05/98/P05 and 26/95/W02CR1414 (1 April 2014) -DDCN 1414/2014Retirement of Standards - DSCNs 03/99/P03, 10/2002, 12/99/A04, 20/98/A03, 30/98/P21, 35/99/P25, 37/97/P24 and 43/97/P29CR1413 (1 April 2014) -DDCN 1413/2014Retirement of Standards - DSCNs 13/97/P07, 15/96/P14, 17/2001, 20/2004, 21/2001, 21/2003, 28/98/P20, 33/2003 and 43/2002CR1409 (1 April 2014) -DDCN 1409/2014Retirement of Standards - DSCN's 46/97/P32, 01/2004, 04/2004, 11/2005, 27/2002, 31/2002, 53/2002 and 54/2002- CR1433 (Immediate) - DDCN 1433/2014 Data Services for Commissioners
- CR1467 (1 April 2014) - DDCN 1467/2014 Retirement of Standards
- CR1464 (1 April 2014) - DDCN 1464/2014 Retirement of Standards - Domains and Diagrams
- CR1458 (1 April 2014) - DDCN 1458/2014 Retirement of Standards - DSCNs - 11/97/P05, 12/97/P06, 15/97/P09, 18/97/P12, 22/96/P19, 32/96/P27, 49/97/P35, 62/95/P51, 07/2007, 08/2009, 17/92, 20/2001, 22/2006 and 38/2002
- CR1444 (1 April 2014) - DDCN 1444/2014 Retirement of Standards
- CR1436 (1 April 2014) - DDCN 1436/2014 Retirement of Standards
- CR1435 (1 April 2014) - DDCN 1435/2014 Retirement of Standards - DSCNs 22/95/P21, 20/91, 21/93, 40/95/P34, 09/94/P04, 93/95/P76, 23/94/A04, 8/92 and 17/93
- CR1432 (1 April 2014) - DDCN 1432/2014 Retirement of Standards - DSCN 3/92, DSCN 12/96/P11, DSCN 50/94/P36, DSCN 66/96/W09 and DSCN 16/93
- CR1429 (1 April 2014) - DDCN 1429/2014 Retirement of Standards - DSCN 07/96/P06
- CR1425 (1 April 2014) - DDCN 1425/2014 Retirement of Standards
- CR1423 (1 April 2014) - DDCN 1423/2014 Retirement of Standards - DSCNs 37/98/A09, 14/97/P08, 12/2002, 37/2003, 14/2004 and 27/2001
- CR1419 (1 April 2014) - DDCN 1419/2014 Retirement of Standards - DSCNs 39/98/A11, 09/99/P06, 11/99/P07, 13/2003, 38/2001, 22/2001, 19/98/A02, 40/96/P34, 29/94/P19, 49/94/P35, 34/95/P29, 53/96/P44 and 96/95/P79
- CR1418 (1 April 2014) - DDCN 1418/2014 Retirement of Standards
- CR1417 (1 April 2014) - DDCN 1417/2014 Retirement of Standards - DSCNs 13/95/P12, 44/2001, 29/2004, 18/98/W02 and 24/98/F01
- CR1416 (1 April 2014) - DDCN 1416/2014 Retirement of Standards - KC64 - DSCNs 05/98/P05 and 26/95/W02
- CR1414 (1 April 2014) - DDCN 1414/2014 Retirement of Standards - DSCNs 03/99/P03, 10/2002, 12/99/A04, 20/98/A03, 30/98/P21, 35/99/P25, 37/97/P24 and 43/97/P29
- CR1413 (1 April 2014) - DDCN 1413/2014 Retirement of Standards - DSCNs 13/97/P07, 15/96/P14, 17/2001, 20/2004, 21/2001, 21/2003, 28/98/P20, 33/2003 and 43/2002
- CR1409 (1 April 2014) - DDCN 1409/2014 Retirement of Standards - DSCN's 46/97/P32, 01/2004, 04/2004, 11/2005, 27/2002, 31/2002, 53/2002 and 54/2002
Release: February 2014
CR1460 (Immediate) -DDCN 1460/2014NHS Dental Services UpdateCR1459 (Immediate) -DDCN 1459/2014General Medical Practitioner (Specified), Doctor Index Number and General Medical Practitioner PPD Code UpdateCR1446 (Immediate) -DDCN 1446/2014Health and Social Care Information Centre UpdateCR1404 (Immediate) -DDCN 1404/2014Retirement of e-Gif definitions- CR1460 (Immediate) - DDCN 1460/2014 NHS Dental Services Update
- CR1459 (Immediate) - DDCN 1459/2014 General Medical Practitioner (Specified), Doctor Index Number and General Medical Practitioner PPD Code Update
- CR1446 (Immediate) - DDCN 1446/2014 Health and Social Care Information Centre Update
- CR1404 (Immediate) - DDCN 1404/2014 Retirement of e-Gif definitions
- CR1395 (28 February 2014) - ISB 0090 Amd 17/2013 Organisation Data Service – NHS Postcode Directory
Release: January 2014
- CR1386 (31 January 2014) - ISB 0090 Amd 9/2013 Special Health Authority (SpHA) Code Structure Change
CR1443 (Immediate) -DDCN 1443/2014Change of name of the National Institute for Health and Clinical ExcellenceCR1441 (Immediate) -DDCN 1441/2014Retirement of Review of Central Returns (ROCR) - Central Return Form KH03ACR1440 (Immediate) -DDCN 1440/2014Retirement of Review of Central Returns (ROCR) - Genitourinary Medicine Access Monthly Monitoring Data SetCR1439 (Immediate) -DDCN 1439/2013Retirement of Review of Central Returns (ROCR) ReturnsCR1405 (Immediate) -DDCN 1405/2013Overseas VisitorsCR1393 (Immediate) -DDCN 1393/2013Amendment to Inter-Provider Transfer Administrative Minimum Data Set OverviewCR1392 (Immediate) -DDCN 1392/2013Review of Central Returns (ROCR) Discontinuations - Referral to Treatment Performance Sharing Data SetCR1391 (Immediate) -DDCN 1391/2013Review of Central Returns (ROCR) Discontinuations - Referral to Treatment (RTT) Summary Patient Tracking List Data Set- CR1443 (Immediate) - DDCN 1443/2014 Change of name of the National Institute for Health and Clinical Excellence
- CR1441 (Immediate) - DDCN 1441/2014 Retirement of Review of Central Returns (ROCR) - Central Return Form KH03A
- CR1440 (Immediate) - DDCN 1440/2014 Retirement of Review of Central Returns (ROCR) - Genitourinary Medicine Access Monthly Monitoring Data Set
- CR1439 (Immediate) - DDCN 1439/2013 Retirement of Review of Central Returns (ROCR) Returns
- CR1405 (Immediate) - DDCN 1405/2013 Overseas Visitors
- CR1393 (Immediate) - DDCN 1393/2013 Amendment to Inter-Provider Transfer Administrative Minimum Data Set Overview
- CR1392 (Immediate) - DDCN 1392/2013 Review of Central Returns (ROCR) Discontinuations - Referral to Treatment Performance Sharing Data Set
- CR1391 (Immediate) - DDCN 1391/2013 Review of Central Returns (ROCR) Discontinuations - Referral to Treatment (RTT) Summary Patient Tracking List Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 June 2014:
- CR1346 (1 June 2014) - ISB 1595 Amd 32/2012 National Neonatal Data Set
Release: November 2013
CR1424 (Immediate) -DDCN 1424/2013Application Identifier (GS1)- CR1424 (Immediate) - DDCN 1424/2013 Application Identifier (GS1)
- CR1367 (29 November 2013) - ISB 0090 Amd 5/2013 Organisation Data Service - Introduction of New Sub Type Identifier for Private Dental Practices
- CR1359 (29 November 2013) - ISB 0090 Amd 47/2012 Organisation Data Service - Identification Codes for Local Authorities
CR1407 (Immediate) -DDCN 1407/2013Clinical InvestigationsCR1415 (Immediate) -DDCN 1415/2013Area TeamsCR1411 (Immediate) -DDCN 1411/2013Update to Supporting Information: SNOMED CT®- CR1407 (Immediate) - DDCN 1407/2013 Clinical Investigations
- CR1415 (Immediate) - DDCN 1415/2013 Area Teams
- CR1411 (Immediate) - DDCN 1411/2013 Update to Supporting Information: SNOMED CT®
Release: September 2013
- CR1348 (1 October 2013) - ISB 1597 Amd 35/2012 Breast Screening Programmes Data Set (KC63 and KC62)
CR1403 (Immediate) -DDCN 1403/2013Religious or Other Belief System AffiliationCR1384 (Immediate) -DDCN 1384/2013Health and Social Care Information Centre Rebranding of XML SchemasCR1397 (Immediate) -DDCN 1397/2013Retired Main Specialty Codes- CR1403 (Immediate) - DDCN 1403/2013 Religious or Other Belief System Affiliation
- CR1384 (Immediate) - DDCN 1384/2013 Health and Social Care Information Centre Rebranding of XML Schemas
- CR1397 (Immediate) - DDCN 1397/2013 Retired Main Specialty Codes
Release: July 2013
- CR1377 (Immediate) - ISB 0105 Retirement of Accident and Emergency Quarterly Monitoring Data Set (QMAE)
Release: May 2013
- CR1363 (Immediate) - ISB 1067 Amd 43/2012 National Workforce Data Set Version 2.6
CR1382 (Immediate) -DDCN 1382/2013National Renal Data Set amendmentCR1381 (Immediate) -DDCN 1381/2013Healthcare Resource Groups- CR1382 (Immediate) - DDCN 1382/2013 National Renal Data Set amendment
- CR1381 (Immediate) - DDCN 1381/2013 Healthcare Resource Groups
- CR1235 (1 June 2013) - ISB 1588 Amd 11/2012 Accident and Emergency Clinical Quality Indicators
Release: April 2013
CR1372 (Immediate) -DDCN 1372/2013Organisation Update: April 2013CR1369 (Immediate) -DDCN 1369/2013Organisation Codes and Organisation Types- CR1372 (Immediate) - DDCN 1372/2013 Organisation Update: April 2013
- CR1369 (Immediate) - DDCN 1369/2013 Organisation Codes and Organisation Types
- CR1347 (1 April 2013) - ISB 1521 Amd 40/2012 Updates to the Cancer Outcomes and Services Data Set and XML Schema
Release: March 2013
CR1364 (Immediate) -DDCN 1364/2013Operating Theatre- CR1364 (Immediate) - DDCN 1364/2013 Operating Theatre
- CR1335 (1 April 2013) - ISB 1593 Amd 27/2012 Venous Thromboembolism Risk Assessment Data Set
- CR1340 (1 April 2013) - ISB 0090 Amd 37/2012 Organisation Data Service - Non-Legislative Organisations
- CR1321 (1 April 2013) - ISB 0011 Amd 25/2012 Mental Health Minimum Data Set version 4.1
Release: February 2013
CR1336 (Immediate) -DDCN 1336/2013XML Schema Constraint PagesCR1362 (Immediate) -DDCN 1362/2013Update to Organisations in the NHS Data Model and DictionaryCR1246 (Immediate) -DDCN 1246/2013Guidance for Merging OrganisationsCR1345 (Immediate) -DDCN 1345/2013e-Government Interoperability Framework (e-GIF) and Government Data Standards CatalogueCR1354 (Immediate) -DDCN 1354/2013Treatment Function Code - Well Babies- CR1336 (Immediate) - DDCN 1336/2013 XML Schema Constraint Pages
- CR1362 (Immediate) - DDCN 1362/2013 Update to Organisations in the NHS Data Model and Dictionary
- CR1246 (Immediate) - DDCN 1246/2013 Guidance for Merging Organisations
- CR1345 (Immediate) - DDCN 1345/2013 e-Government Interoperability Framework (e-GIF) and Government Data Standards Catalogue
- CR1354 (Immediate) - DDCN 1354/2013 Treatment Function Code - Well Babies
Release: December 2012
- CR1155 (Immediate) - ISB 1567 Amd 12/2011 National Joint Registry Data Set Version 5
- CR1324 (1 December 2012) - ISB 1067 Amd 23/2012 Workforce Data Set Version 2.5
- CR1196, CR1287 and CR1195 (1 January 2013) - ISB 1521 Amd 64/2010 Cancer Outcomes and Services Data Set, Cancer Outcomes and Services Data Set Message and Retirement of Cancer Registration Data Set and National Cancer Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
- CR1337 (1 April 2013) - ISB 1072 Amd 30/2012 Update to Child and Adolescent Mental Health Services Secondary Uses Data Set
Release: November 2012
- CR1166, CR1167 and CR1306 (1 November 2012) - ISB 0092 Amd-16-2010 Commissioning Data Set Version 6-2, Commissioning Data Set XML Message Version 6-2 and Retirement of CDS 6-0
- CR1305 (1 April 2013) - ISB 0092 Amd 06/2011 Allied Health Professions Referral to Treatment (AHP RTT) Update - CDS 6-2
- CR1286 (1 November 2012) - ISB 0028 Amd 17/2012 Treatment Function Codes Update
CR1343 (Immediate) -DDCN 1343/2012Change of name for NHS Commissioning Board AuthorityCR1342 (Immediate) -DDCN 1342/2012Overseas Visitors UpdateCR1341 (Immediate) -DDCN 1341/2012Discharge Default Code Descriptions- CR1343 (Immediate) - DDCN 1343/2012 Change of name for NHS Commissioning Board Authority
- CR1342 (Immediate) - DDCN 1342/2012 Overseas Visitors Update
- CR1341 (Immediate) - DDCN 1341/2012 Discharge Default Code Descriptions
- CR1323 (Immediate) - National Cancer Waiting Times Monitoring Data Set Update for "Delay Reason To Treatment For Cancer"
CR1323 is a corrigendum to CR1258 (1 July 2012) - ISB 0147 Amd 23/2011 Changes to the National Cancer Waiting Times Monitoring Data Set published in the June 2012 release
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
CR1231 and CR1288 (1 April 2013) - ISB 1570 Amd 164/2010 HIV and AIDS Reporting Data Set and HIV and AIDS Related Data Set Message
Release: September 2012
- CR1103 (Immediate) - ISB 0066 Amd 43/2010 Renal Data Set - Data Item Addition, Changes and Deletions
CR1334 (Immediate) -DDCN 1334/2012Psychology DefinitionsCR1331 (Immediate) -DDCN 1331/2012Activity Date Time TypeCR1329 (Immediate) -DDCN 1329/2012Change of name for "Health and Social Care Information Centre"- CR1334 (Immediate) - DDCN 1334/2012 Psychology Definitions
- CR1331 (Immediate) - DDCN 1331/2012 Activity Date Time Type
- CR1329 (Immediate) - DDCN 1329/2012 Change of name for "Health and Social Care Information Centre"
Release: August 2012
CR1326 (Immediate) -DDCN 1326/2012Health and Care Professions CouncilCR1241 (Immediate) -DDCN 1241/2012NHS dictionary of medicines and devicesCR1292 (Immediate) -ISB 1549 Amd 4/2011andDDCN 1292/2012Deprecation and withdrawal of version 3.2 of the Acute Myocardial Infarction Data Set and subsequent retiring of the Data Set from the NHS Data Model and Dictionary- CR1326 (Immediate) - DDCN 1326/2012 Health and Care Professions Council
- CR1241 (Immediate) - DDCN 1241/2012 NHS dictionary of medicines and devices
- CR1292 (Immediate) - ISB 1549 Amd 4/2011 and DDCN 1292/2012 Deprecation and withdrawal of version 3.2 of the Acute Myocardial Infarction Data Set and subsequent retiring of the Data Set from the NHS Data Model and Dictionary
Release: June 2012
CR1314 (Immediate) -DDCN 1314/2012Reasonable Offer Update- CR1314 (Immediate) - DDCN 1314/2012 Reasonable Offer Update
- CR1282 (29 June 2012) - ISB 0090 Amd 36/2011 Independent Sector Healthcare Provider (ISHP) Codes extended for ISHPs and Sites
- CR1258 (1 July 2012) - ISB 0147 Amd 23/2011 Changes to the National Cancer Waiting Times Monitoring Data Set
Release: May 2012
- CR1215 (1 June 2012) - ISB 1067 Amd 30/2011 National Workforce Data Set
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2013:
- CR1028 (1 April 2013) - ISB 1069 Amd 14/2012 Children and Young People's Health Services Data Set
- CR1029 (1 April 2013) - ISB 1072 Amd 12/2012 Child and Adolescent Mental Health Services (CAMHS) Data Set
- CR1104 (1 April 2013) - ISB 1513 Amd 13/2012 Maternity Secondary Uses Data Set
Release: March 2012
CR1242 (Immediate) -DDCN 1242/2012Retirement of Mental Health Minimum Data Set Version 3- CR1242 (Immediate) - DDCN 1242/2012 Retirement of Mental Health Minimum Data Set Version 3
- CR1238 and CR1276 (1 April 2012) - ISB 1577 Amd 10/2011 Diagnostic Imaging Data Set and Diagnostic Imaging Data Set Message v 1-0
CR1290 (Immediate) -DDCN 1290/2012Data Set Notation- CR1290 (Immediate) - DDCN 1290/2012 Data Set Notation
- CR1263 (Immediate) - ISB 0090 Amd 5/2012 Health and Social Care Bill Changes
- CR1255 (31 March 2012) - ISB 1576 Amd 08/2011 Quarterly Bed Availability and Occupancy Data Set
- CR1295 (Immediate) - Retirement of old Commissioning Data Set messages
The Information Standards Board for Health and Social Care have been involved in the redesign and retirement of the old Commissioning Data Set Pages, however a formal Information Standards Notice (ISN) will not be published as there are no changes to data standards.
Release: January 2012
CR1285 (Immediate) -DDCN 1285/2012Elective Admission TypeCR1252 (Immediate) -DDCN 1252/2011Geographic Area Changes- CR1285 (Immediate) - DDCN 1285/2012 Elective Admission Type
- CR1252 (Immediate) - DDCN 1252/2011 Geographic Area Changes
Release: November 2011
- CR1264 (Immediate) - ISB 1077 Amd 3/2012 Automatic Identification and Data Capture (AIDC) for Patient Identification Data Set
CR1274 (Immediate) -DDCN 1274/2011CDS Prime Recipient Identity UpdateThe following have been incorporated early to allow users to see the changes, but please note that the implementation date is1 April 2012:- CR1274 (Immediate) - DDCN 1274/2011 CDS Prime Recipient Identity Update
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
CR1265 (1 April 2012) - ISB 1520 Amd 29/2011 Changes to the Improving Access to Psychological Therapies Data Set
Release: October 2011
CR1271 (Immediate) -DDCN 1271/2011Commissioning Data Set Addressing Grid UpdateCR1268 (Immediate) -DDCN 1268/2011Sexual Orientation Code- CR1271 (Immediate) - DDCN 1271/2011 Commissioning Data Set Addressing Grid Update
- CR1268 (Immediate) - DDCN 1268/2011 Sexual Orientation Code
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
- CR1158 and CR1260 (1 April 2012) - ISB 1533 Amd 63/2010 Systemic Anti-Cancer Therapy Data Set and Systemic Anti-Cancer Therapy Data Set Message Schema
The following have been incorporated early to allow users to see the changes, but please note that the implementation date is 1 July 2012:
- CR1270 (1 July 2012) - ISB 1080 Amd 25/2011 Amendments to NHS Health Check Data Set
- CR1250 (1 July 2012) - ISB 1080 Amd 25/2011 NHS Health Checks Data Set Message Schema Version 2.0.0
Release: August 2011
- CR1232 (Immediate) - ISB 0034 Amd 26/2006 Systematized Nomenclature of Medicine Clinical Terms (SNOMED CT) - NHS Data Model and Dictionary Overview
- CR1222 (1 April 2012) - ISB 0021 Amd 86/2010 Introduction of the International Classification of Diseases Tenth Revision 4th Edition
- CR1190 (1 September 2011) - ISB 1538 Amd 131/2010 Chlamydia Testing Activity Data Set
- CR1188 (Immediate) - Amd 85/2010 Genitourinary Medicine Clinic Activity Data Set (GUMCAD) Extension to include Enhanced Sexual Health Services (ESHS)
The following data set is initially being introduced for local use only. A future Information Standards Notice will be published to notify providers and system suppliers of the requirement to flow the data set nationally:
- CR1105 (1 April 2012) - ISB 1510 Amd 25/2010 Community Information Data Set
Release: July 2011
CR1249 (Immediate) -DDCN 1249/2011General Pharmaceutical Council Registration Changes- CR1249 (Immediate) - DDCN 1249/2011 General Pharmaceutical Council Registration Changes
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 July 2012:
- CR1148 (1 July 2012) - ISB 1080 Amd 129/2010 NHS Health Checks Data Set
Release: June 2011
CR1256 (Immediate) -DDCN 1256/2011School Definitions- CR1256 (Immediate) - DDCN 1256/2011 School Definitions
- CR1117 (26 August 2011) - ISB 0090 Amd 94/2010 Organisation Data Service Identification Codes for Local Authorities in England and Wales
CR1251 (Immediate) -DDCN 1251/2011Change to the Format/Length of Weekly Hours WorkedCR1243 (Immediate) -DDCN 1243/2011National Interim Clinical Imaging Procedure (NICIP) Code Set- CR1251 (Immediate) - DDCN 1251/2011 Change to the Format/Length of Weekly Hours Worked
- CR1243 (Immediate) - DDCN 1243/2011 National Interim Clinical Imaging Procedure (NICIP) Code Set
Release: April 2011
- CR1154 (1 April 2011) - ISB 0011 Amd 87/2010 Mental Health Minimum Data Set Version 4.0
CR1234 (Immediate) -DDCN 1234/2011Technology Reference Data Update Distribution Service (TRUD)- CR1234 (Immediate) - DDCN 1234/2011 Technology Reference Data Update Distribution Service (TRUD)
- CR1168 (Immediate) - ISB 0097 Amd 140/2010 Genitourinary Medicine Access Monthly Monitoring Data Set Amendments - Removal of Human Immunodeficiency Virus data
The following has been incorporated early to allow users to see the changes, but please note that the implementation date is 1 April 2012:
- CR1050 (1 April 2012) - ISB 1520 Amd 51/2010 Improving Access to Psychological Therapies Data Set
Release: March 2011
- CR1224 (1 April 2011) - ISB 0092 Amd 02/20110 Commissioning Data Set Schema Version 6-1-1
CR1223 (Immediate) -DDCN 1223/2011Updates to Family Planning ReferencesCR1225 (Immediate) -DDCN 1225/2011Practitioners with Special Interests- CR1223 (Immediate) - DDCN 1223/2011 Updates to Family Planning References
- CR1225 (Immediate) - DDCN 1225/2011 Practitioners with Special Interests
- CR1216 (1 April 2011) - ISB 0028 Amd 170/2010 Changes to Treatment Function Codes
- CR1203 (1 April 2011) - ISB 0084 Amd 150/2010 Introduction of OPCS Classification of Interventions and Procedures Version 4.6
Release: January 2011
- CR1116 (1 April 2010) - ISB 0003 Amd 79/2010 Immunisation Programmes Activity Data Set (KC50)
- CR1112 (1 April 2010) - ISB 1511 Amd 26/2010 NHS Continuing Healthcare and NHS Funded Nursing Care
- CR1068 (Immediate) - ISB 0133 Amd 161/2010 Change To Central Return: Human Papillomavirus (HPV) Immunisation Programme - Vaccine Monitoring Minimum Data Set
CR1211 (Immediate) -DDCN 1211/2010Commissioning Data Set Addressing Grid / Organisation Code (Code of Commissioner) Update- CR1211 (Immediate) - DDCN 1211/2010 Commissioning Data Set Addressing Grid / Organisation Code (Code of Commissioner) Update
Release: December 2010
- CR1175 (1 April 2011) - ISB 1518 Amd 166/2010 Changes to Sexual and Reproductive Health Activity Data Set
- CR1198 (Immediate) - ISB 1067 Amd 165/2010 National Workforce Data Set
- CR1207 (01 December 2010) - ISB 1573 Amd 168/2010 Mixed-Sex Accommodation
- CR1149 (01 January 2011) - ISB 0139 Amd 99/2010 GUMCAD: Change to Genitourinary (GU) Episode Types
Release: November 2010
CR1192 (Immediate) -DDCN 1192/2010Change of name for "Health Solution Wales"CR1199 (Immediate) -DDCN 1199/2010General Pharmaceutical Council and Royal Pharmaceutical Society of Great Britain UpdateCR1189 (Immediate) -DDCN 1189/2010National Institute for Health and Clinical ExcellenceCR1187 (Immediate) -DDCN 1187/2010Introduction of the Department for Education- CR1192 (Immediate) - DDCN 1192/2010 Change of name for "Health Solution Wales"
- CR1199 (Immediate) - DDCN 1199/2010 General Pharmaceutical Council and Royal Pharmaceutical Society of Great Britain Update
- CR1189 (Immediate) - DDCN 1189/2010 National Institute for Health and Clinical Excellence
- CR1187 (Immediate) - DDCN 1187/2010 Introduction of the Department for Education
Release: September 2010
CR1128 (Immediate) -DDCN 1128/2010Changes to reporting procedures for Overseas Visitors from the European Economic Area and SwitzerlandCR1173 (Immediate) -DDCN 1173/2010Care Quality Commission UpdateCR1143 (Immediate) -DDCN 1143/2010General Pharmaceutical Council- CR1128 (Immediate) - DDCN 1128/2010 Changes to reporting procedures for Overseas Visitors from the European Economic Area and Switzerland
- CR1173 (Immediate) - DDCN 1173/2010 Care Quality Commission Update
- CR1143 (Immediate) - DDCN 1143/2010 General Pharmaceutical Council
- CR1061 (1 October 2010) - ISB 0092/2010 CDS Type 20: Out-patient: Retirement of Default Codes for Out-patient Procedures
- CR1133 (Immediate) - ISB 00289/2010 National Specialty List
Release: August 2010
- The August 2010 Release introduces the NHS Data Model and Dictionary Help Pages.
Release: July 2010
- CR1134 (Immediate - ISB 1067/2010 Amd 109/2010 National Workforce Data Set
- CR1082 (Immediate) - ISB 0153/2010 Critical Care Minimum Data Set
- CR1121 (Immediate) - DSCN 17/2010 Retirement of Data Standard KC60 Central Return
Release: May 2010
- CR957 (Immediate) - DSCN 19/2010 Central Returns: KA34 Ambulance Services
- CR1069 (Immediate) - Redesign of the Commissioning Data Set Pages
The Information Standards Board for Health and Social Care have been involved in the redesign of the Commissioning Data Set Pages and are satisfied that it meets the requirements of the service, however a formal Information Standards Notice (ISN) will not be published as there are no changes to data standards.
Release: March 2010
- CR1123 (1 April 2010) - DSCN 18/2010 Information Standards Notice (ISN)
- CR1139 (Immediate) - DSCN 16/2010 Person Weight
- CR1130 (Immediate) - DSCN 15/2010 Change of name for "The NHS Information Centre for health and social care"
- CR1013 (April 2010) - DSCN 14/2010 Sexual and Reproductive Health Activity Dataset (SRHAD)
- CR1125 (Immediate) - DSCN 13/2010 NHS Data Model and Dictionary Maintenance Update - Policy Definitions
- CR1122 (Immediate) - DSCN 11/2010 Changes to Family Planning References
Release: January 2010
- CR1115 (Immediate) - DSCN 10/2010 Data Standards: Updating of e-Government Interoperability Framework and Government Data Standards Catalogue References
Release: December 2009
- CR1100 (Immediate) - DSCN 25/2009 NHS Prescription Services Update
- CR1045 (1 December 2009) - DSCN 17/2009 Referral to Treatment Clock Stop Administrative Event
- CR1003 (1 December 2009) - DSCN 16/2009 Commissioning Data Sets: Mandation of 18 Week Referral To Treatment Data Items
Release: November 2009
- CR1113 (Immediate) - DSCN 24/2009 Information Standards Board for Health and Social Care Update
- CR1087 (Immediate) - DSCN 23/2009 Health Professions Council Update
- CR1081 (Immediate) - DSCN 22/2009 Data Standards: NHS Data Model and Dictionary Maintenance Update
- CR1019 (27 November 2009) - DSCN 21/2009 Data Standards: Organisation Data Service (ODS) - Optical Sites and Optical Headquarters
- CR1034 (27 November 2009) - DSCN 20/2009 Data Standards: Organisation Data Service (ODS) - Care Homes in England and Wales and their Headquarters
Release: September 2009
- CR1065 (1 October 2009) - DSCN 15/2009 Data Standards: Organisation Data Service, Local Health Boards
Release: June 2009
- CR1014 (1 June 2009) - DSCN 13/2009 Religious and Other Belief System Affiliation
- CR1074 (Immediate) - DSCN 12/2009 Data Standards: Care Quality Commission
- CR1056 (Immediate) - DSCN 11/2009 Data Standards: NHS Data Model and Dictionary Maintenance Update
- CR1072 (1 December 2009) - DSCN 10/2009 Data Standards: National Radiotherapy Data Set
- CR1073 (Immediate) - DSCN 09/2009 Central Returns: Diagnostic Waiting Times and Activity Data Set
- CR1066 (Immediate) - DSCN 08/2009 Data Standards: NHS Prescription Services and NHS Dental Services
- CR1047 (1 April 2011) - DSCN 07/2009 Data Standards: Diabetic Retinopathy Screening Dataset v3.6
- CR1059 (Immediate) - DSCN 06/2009 Data Standard: National Workforce Data Set v2.1
- CR914 (April 2008 (Retrospective)) - DSCN 05/2009 NHS Stop Smoking Services Quarterly Monitoring Return
- CR899 (Immediate) - DSCN 02/2009 NHS Data Model and Dictionary Maintenance Update
Release: March 2009
- CR1001 (1 April 2009) - DSCN 03/2009 Introduction of Commissioning Data Set Schema Version 6-1 (2008-04-01) and update to Commissioning Data Set Schema Version 6-0 (2008-01-14)
- CR976 (31 March 2009) - DSCN 26/2008 Subject: KP90 - Admissions, Changes in Status and Detentions under the Mental Health Act
- CR1017 (1 April 2009) - DSCN 25/2008 Critical Care Minimum Data Set
- CR1002 (1 April 2009) - DSCN 24/2008 Data Standards: Introduction of Commissioning Dataset Version 6.1
- CR1016 (Immediate) - DSCN 23/2008 4 Byte Version of the Read Codes - Withdrawal
Release: December 2008
- CR1022 (1 January 2009) - DSCN 29/2008 Data Standards: 18 Weeks Referral to Treatment (RTT) Time, Performance Sharing
- CR901 (Immediate) - DSCN 28/2008 Removal of references to EDIFACT and the NHS Wide Clearing Service (NWCS)
- CR843 (1 April 2009) - DSCN 22/2008 Data Standards: National Radiotherapy Data Set
- CR1011 (1 January 2009) - DSCN 20/2008 Data Standards: National Cancer Waiting Times Minimum Data Set
Release: November 2008
- CR1026 (3 November 2008) - DSCN 21/2008 Information Standard: Mental Health Act 2007 Mental Category
Release: August 2008
- CR1018 (Immediate) - DSCN 19/2008 Data Standards: Change of Name for National Administrative Code Services (NACS) to Organisation Data Service (ODS)
- CR956 (1 September 2008) - DSCN 18/2008 Central Return: Human Papillomavirus (HPV) Immunisation Programme, Vaccine Monitoring Minimum Dataset
- CR861 (Immediate) - DSCN 16/2008 Central Return: Hospital and Community Services Complaints and General Practice (including Dental) Complaints - KO41(a) and KO 41(b)
- CR964 (Immediate) - DSCN 14/2008 Central Return: 18 Weeks ‘Adjusted’ Referral to Treatment (RTT) Dataset
- CR965 (Immediate) - DSCN 13/2008 Data Standards: Organisation Data Service (ODS) - Change to the Default Codes Set to Support Changes to GMS Contract
- CR879 (Immediate) - DSCN 12/2008 Data Standards: Quarterly Monitoring: Cancelled Operations Data Set (QMCO)
Release: May 2008
- CR502 (Immediate) - DSCN 10/2008 Data Standards: National Workforce Data Definitions (v2.0)
- CR910 (1 April 2008) - DSCN 08/2008 Data Standards: National Direct Access Audiology Patient Tracking List (PTL) and Waiting Times (WT) data sets
- CR900 (Immediate) - DSCN 07/2008 Data Standards: Inter-Provider Transfer Administrative Minimum Data Set
- CR934 (1 April 2008) - DSCN 06/2008 Data Standards: Mental Health Minimum Data Set (version 3.0)
- CR935 (Immediate) - DSCN 05/2008 Data Standards: 18 Weeks Rules Suite
- CR925 (1 September 2008) - DSCN 04/2008 Genitourinary Medicine Clinic Activity Data Set Change to an Information Standard
- CR942 (1 June 2008) - DSCN 03/2008 General Practice and General Medical Practitioner (GMP) - changes resulting from the introduction of the General Medical Services (GMS) Contract
Release: February 2008
- CR812 (Immediate) - DSCN 01/2008 Central Return: Diagnostics Waiting Times Census Data Set
- CR881 (31 December 2007) - DSCN 42/2007 Central Return: Referral To Treatment Summary Patient Tracking List
- CR904 (Immediate) - DSCN 41/2007 Data Standards: Admission Intended Procedure Update
- CR824 (1 February 2008) - DSCN 39/2007 Data Standards: 48 Hour Genitourinary Medicine Access Monthly Monitoring (GUMAMM)
Release: November 2007
- CR919 (Immediate) - DSCN 38/2007 Data Standards: Mental Health Minimum Data Set Schema
- CR814 (1 April 2008) - DSCN 37/2007 Data Standards: Introduction of Mental Health Minimum Data Set version 2.1
- CR930 (31 December 2007) - DSCN 35/2007 Data Standards: A correction to the version 6 Commissioning Data Set schema
- CR834 (Immediate) - DSCN 34/2007 Data Standards: Referral Request Received Date
- CR875 (Immediate) - DSCN 33/2007 Data Standards: National Administrative Codes Service: Introduction of codes for the new Pan SHAs
- CR880 (Immediate) - DSCN 29/2007 Data Standards: Amendments to Doctor Index Number (DIN) Description
Release: August 2007
- CR845 (Immediate) - DSCN 28/2007 Data Standards: Treatment Function Code (Referral to Treatment Period)
- CR831 (1 October 2007) - DSCN 27/2007 Data Standards: Update to Commissioning Data Set XML Schema v5
- CR825 (1 October 2007) - DSCN 16/2007 Data Standards: Source of Referral for Outpatients (18 Weeks)
Release: June 2007
- CR799 (31 December 2007) - DSCN 18/2007 Data Standards: Introduction of Commissioning Data Set Version 6
- CR833 (Immediate) - DSCN 17/2007 Data Standards: Introduction of Commissioning Data Set validation table
- CR801 (Immediate) - DSCN 15/2007 Data Standards: Cover of Vaccination Evaluated Rapidly (COVER) Return
Release: May 2007
- CR800 (31 December 2007) - DSCN 14/2007 Commissioning Data Set Schema Version 6-0
- CR856 (1 October 2007) - DSCN 13/2007 Data Standards: Discharge Ready Date
- CR869 (Immediate) - DSCN 12/2007 Data Standards: Update to Clinical Coding Introduction
- CR827 (1 October 2007) - DSCN 09/2007 Data Standards: Earliest Reasonable Offer Date
- CR817 (1 October 2007) - DSCN 08/2007 Data Standards: Introduction of Age into Commissioning Data Sets
- CR849 (May 2007) - DSCN 07/2007 National Administrative Codes Service: Introduction of new identification codes for Dental Consultants
- CR822 (Immediate) - DSCN 06/2007 Data Standards: Update to Organisation Codes
- CR850 (Immediate) - DSCN 05/2007 National Administrative Codes Service: Amendments to Default Codes
- CR786 (1 April 2007) - DSCN 04/2007 Quarterly Monitoring Accident and Emergency Services (QMAE) Central Return
Release: February 2007
- CR811 (Immediate) - DSCN 03/2007 Diagnostic Waiting Times and Activity
- CR826 (1 October 2007) - DSCN 02/2007 Extension of Treatment Function to Support the Measurement of 18 Week Referral to Treatment Periods
- CR813 (1 April 2007) - DSCN 01/2007 Paediatric Critical Care Minimum Data Set
- CR768 (1 January 2007) - DSCN 18/2006 Changes to the NHS Data Dictionary to support the measurement of 18 week referral to treatment periods
- CR798 (6 November 2006) - DSCN 19/2006 Commissioning Data Set (CDS) Version 5 XML Message Schema
- CR776 (1 October 2006) - DSCN 05/2006 Data Standards: Accident and Emergency Enhancements to Investigation and Treatment Codes
Release: September 2006
- CR795 (31 October 2006) - DSCN 22/2006 Organisation Codes / Organisation Site Codes
- CR792 (1 April 2007) - DSCN 15/2006 Neonatal Critical Care
- CR719 (1 April 2006) - DSCN 09/2006 Measuring and Recording of Waiting Times
- CR791 (1 April 2007) - DSCN 13/2006 Priority Type
- CR774 (1 September 2006) - DSCN 12/2006 Person Marital Status
Release: May 2006
- CR764 (1 April 2006) - DSCN 08/2006 Diagnostics waiting times and activity
- Correction to menu structure to include Critical Care Minimum Data Set
Release: April 2006
- CR608 (1 October 2006) - DSCN 07/2006 Introduction of Commissioning Data Set Version 5 and its associated XML schema into the NHS Data Dictionary.
- CR756 (1 September 2005) - DSCN 19/2005 PbR Commissioning for Out of Area Treatments (OATs) and Charge-Exempt Overseas Visitors
- CR724 (1 April 2006) - DSCN 13/2005 Critical Care Minimum Data Set
- CR754 (1 April 2006) - DSCN 17/2005 Treatment Function and Main Specialty Code Revisions
- CR763 (1 April 2006) - DSCN 20/2005 New Treatment Functions for therapy services and anticoagulant service
- CR767 (Immediate) - DSCN 02/2006 Referral Request Received Date
- CR690 (1 September 2005) - DSCN 16/2005 Marital Status
Release: August 2005
- CR555 (1 April 2005) - DSCN 11/2005 Data Standards: COVER - Hepatitis B immunisation for babies
- CR715 (Immediate) - DSCN 10/2005 Data Standards: Treatment Function Codes - correction and clarification of names and descriptions
- CR706 (1 April 2005) - DSCN 09/2005 Data Standards: Cancer Registration Data Set
- CR691 (1 July 2005) - DSCN 06/2005 Data Standards: NSCAG Commissioner Code
Change to Supporting Information: Changed Description
|
The What's New page shows the Information Standards Notices that have been incorporated into each release of the NHS Data Model and Dictionary. The associated Information Standards Notice, Data Set Change Notice and Data Dictionary Change Notice can be accessed by selecting the hyperlink. It is important to note that the Information Standards Notice implementation date determines when it will be published in the NHS Data Model and Dictionary. Information Standards Notices not yet incorporated into the NHS Data Model and Dictionary are still approved standards. What would you like to do next?
|
Change to Class: Changed Attributes
| K | ACTIVITY IDENTIFIER | |
| EXPECTED DELAY BEFORE ACTIVITY UNIT | ||
| EXPECTED DELAY BEFORE ACTIVITY VALUE | ||
Change to Class: Changed Attributes
| A and E INCIDENT LOCATION TYPE | ||
| A and E PATIENT GROUP | ||
| ACTIVITY GROUP TYPE | ||
| ADMISSION METHOD | ||
| ASSAULT METHOD | ||
| BABY FIRST FEED BREAST MILK STATUS | ||
| BREASTFEEDING STATUS | ||
| CANCER OR SYMPTOMATIC BREAST REFERRAL PATIENT STATUS | ||
| CANCER TRANSFER REASON FOR INTER PROVIDER TRANSFER | ||
| CANCER TREATMENT INTENT | ||
| CARE PROGRAMME APPROACH REVIEW ABUSE QUESTION ASKED INDICATOR | ||
| CARER RESIDENT INDICATION CODE FOR NATIONAL NEONATAL DATA SET | ||
| CHILDREN TEENAGERS AND YOUNG ADULTS AGE CATEGORY | ||
| COMMUNITY TREATMENT ORDER END REASON | ||
| COMPLEX SOCIAL FACTORS INDICATOR | ||
| DAUGHTER BORN AT THIS ENCOUNTER INDICATOR | ||
| DELIVERY PLACE CHANGE REASON | ||
| DISCHARGE DESTINATION | ||
| DISCHARGED TO HOSPITAL AT HOME SERVICE INDICATOR | ||
| DISCHARGE METHOD | ||
| EMERGENCY CARE ATTENDANCE CATEGORY | ||
| ESTIMATED DATE OF DELIVERY | ||
| ESTIMATED DATE OF DELIVERY METHOD | ||
| FEMALE GENITAL MUTILATION AGE CATEGORY | ||
| FIRST REGULAR DAY OR NIGHT ADMISSION | ||
| HEALTHCARE RESOURCE GROUP CODE | ||
| IMPROVING ACCESS TO PSYCHOLOGICAL THERAPIES CARE SPELL END CODE | ||
| IMPROVING ACCESS TO PSYCHOLOGICAL THERAPIES OPT IN DATE | ||
| IMPROVING ACCESS TO PSYCHOLOGICAL THERAPIES STEPPED CARE INTENSITY DELIVERED | ||
| IN LABOUR BEFORE CAESARIAN SECTION INDICATOR | ||
| INTENDED DELIVERY PLACE | ||
| INTRAVESICAL CHEMOTHERAPY RECEIVED INDICATOR | ||
| INTRAVESICAL IMMUNOTHERAPY RECEIVED INDICATOR | ||
| LENGTH OF STAY ADJUSTMENT | ||
| LENGTH OF STAY ADJUSTMENT REASON | ||
| MATERNAL CRITICAL INCIDENT TYPE | ||
| MECONIUM PRESENT IN LIQUOR INDICATOR | ||
| MENTAL HEALTH ABSOLUTE DISCHARGE RESPONSIBILITY | ||
| MENTAL HEALTH CONDITIONAL DISCHARGE END REASON | ||
| MENTAL HEALTH DELAYED DISCHARGE ATTRIBUTABLE TO INDICATION CODE | ||
| MENTAL HEALTH DELAYED DISCHARGE REASON | ||
| METHOD OF COMMUNICATION FOR END OF CANCER FASTER DIAGNOSIS PATHWAY | ||
| MONITORING INTENT | ||
| MOTHER ANTENATALLY BOOKED INDICATOR | ||
| NEONATAL CRITICAL INCIDENT TYPE | ||
| NEONATAL LEVEL OF CARE | ||
| NON SMOKING CONFIRMATION STATUS AT 4 WEEKS | ||
| ORGAN OR TISSUE UNSUITABLE ORGAN CODE RENAL TRANSPLANT | ||
| OUTCOME AT 4 WEEK FOLLOW UP FOR STOP SMOKING | ||
| PAEDIATRIC NEPHROLOGY REGISTRY STATUS CODE | ||
| PALLIATIVE CARE SPECIALIST SEEN INDICATOR | ||
| PALLIATIVE TREATMENT REASON CODE FOR UPPER GASTROINTESTINAL | ||
| PATIENT CLASSIFICATION | ||
| PATIENT RECEIVING ONE TO ONE NURSING CARE INDICATOR | ||
| PHARMACOTHERAPY STOP SMOKING AID RECEIVED | ||
| PREGNANCY OUTCOME CODE | ||
| PREGNANCY PREVIOUS CAESAREAN SECTIONS | ||
| PREGNANCY TOTAL LIVE BIRTHS | ||
| PREGNANCY TOTAL PREVIOUS LOSSES LESS THAN 24 WEEKS | ||
| PREGNANCY TOTAL PREVIOUS PREGNANCIES | ||
| PREGNANCY TOTAL STILL BIRTHS | ||
| PREVIOUS NEGATIVE HIV TEST INDICATOR | ||
| RADIOTHERAPY INTENT | ||
| RENAL DIALYSIS SCHEDULE TYPE | ||
| SOURCE OF ADMISSION | ||
| TIME BETWEEN DELIVERY AND SPONTANEOUS RESPIRATION CODE |
Change to Class: Changed Attributes
| COMMUNITY CARE ACTIVITY TYPE CODE | ||
| GROUP THERAPY INDICATOR | ||
| SEXUAL AND REPRODUCTIVE HEALTH CARE ACTIVITY | ||
Change to Class: Changed Attributes
| A and E ATTENDANCE CATEGORY | ||
| A and E INITIAL ASSESSMENT TRIAGE CATEGORY | ||
| A and E STREAM | ||
| ACCIDENT AND EMERGENCY ARRIVAL MODE | ||
| ACCIDENT AND EMERGENCY ATTENDANCE DISPOSAL | ||
| ANTIRETROVIRAL THERAPY DRUG REGIMEN GROUP CODE | ||
| ANTIRETROVIRAL THERAPY HOME DELIVERY INDICATOR | ||
| BRIEF INTERVENTION PROVIDED INDICATOR | ||
| BRIEF INTERVENTION TYPE FOR NHS HEALTH CHECK | ||
| CARE CONTACT CANCELLATION REASON | ||
| CARE CONTACT SUBJECT | ||
| CARE CONTACT TYPE | ||
| CHILD DIFFICULT TO TEST REASON | ||
| CLINICAL NURSE SPECIALIST INDICATION CODE | ||
| CLINIC ATTENDANCE PURPOSE CODE FOR HIV | ||
| COLPOSCOPY PRIME PROCEDURE TYPE | ||
| CONSULTATION MEDIUM USED | ||
| CONSULTATION TYPE | ||
| CONTRACEPTIVE SERVICE TYPE | ||
| DECISION TO UNDERTAKE FURTHER ASSESSMENT INDICATOR | ||
| DIETARY ADVICE REASON CODE | ||
| EMPLOYMENT SUPPORT SUITABILITY INDICATOR | ||
| FACE TO FACE COMMUNICATION MODE | ||
| FEMALE GENITAL MUTILATION IDENTIFICATION METHOD CODE | ||
| FIRST ANTIRETROVIRAL THERAPY IN THE UNITED KINGDOM INDICATOR | ||
| FIRST ATTENDANCE | ||
| FIVE FORENSIC PATHWAYS ASSESSMENT REASON | ||
| FIVE FORENSIC PATHWAYS CODE | ||
| FURTHER ASSESSMENT TYPE FOR NHS HEALTH CHECK | ||
| HOLISTIC NEEDS ASSESSMENT POINT OF PATHWAY FOR CANCER | ||
| INFORMATION AND ADVICE PROVIDED INDICATOR | ||
| INFORMATION AND ADVICE TYPE PROVIDED FOR FEMALE GENITAL MUTILATION | ||
| INFORMATION AND ADVICE TYPE PROVIDED FOR NHS HEALTH CHECK | ||
| INITIAL CONTACT INDICATOR | ||
| INITIAL DIAGNOSIS CARE SETTING OR SERVICE FOR HIV | ||
| MEDICAL STAFF TYPE SEEING PATIENT | ||
| MENTAL HEALTH PREDICTION AND DETECTION INDICATOR | ||
| METASTATIC STATUS | ||
| MULTIPROFESSIONAL OR MULTIDISCIPLINARY INDICATION CODE | ||
| NEW HIV DIAGNOSIS IN UNITED KINGDOM INDICATOR | ||
| OTHER PERSON IN ATTENDANCE AT CARE CONTACT | ||
| OUTCOME OF ATTENDANCE | ||
| PATIENT EXPOSURE TO HIV | ||
| PATIENT HIV CARE STATUS | ||
| PATIENT TRIAL STATUS FOR CANCER | ||
| POST EXPOSURE PROPHYLAXIS INDICATOR | ||
| POSTNATAL CARE INDICATOR | ||
| PRE EXPOSURE PROPHYLAXIS INDICATOR | ||
| PREGNANCY INDICATOR FOR HIV | ||
| PSYCHIATRIC CARE INDICATOR FOR HIV | ||
| SIGNPOSTING TO SERVICE INDICATOR | ||
| SIGNPOSTING TO SERVICE TYPE FOR NHS HEALTH CHECK | ||
| SKIN TO SKIN CONTACT INDICATOR | ||
| SOCIAL WORKER CARE INDICATOR FOR HIV | ||
| SUBJECTIVE GLOBAL ASSESSMENT | ||
| THERAPY TYPE FOR IMPROVING ACCESS TO PSYCHOLOGICAL THERAPIES | ||
| TWO YEAR NEONATAL OUTCOMES ASSESSMENT NOT CARRIED OUT REASON |
Change to Class: Changed Attributes
| ABDOMINAL XRAY PERFORMED REASON | ||
| ABDOMINAL XRAY PERFORMED TO INVESTIGATE ABDOMINAL SIGNS INDICATOR | ||
| ABLATIVE THERAPY TYPE | ||
| ACCIDENT AND EMERGENCY INVESTIGATION | ||
| ACCIDENT AND EMERGENCY TREATMENT | ||
| ADDITIONAL UNPLANNED PROCEDURE REQUIRED INDICATOR | ||
| ADJUNCTIVE THERAPY TYPE | ||
| ANAESTHESIA TYPE IN LABOUR AND DELIVERY | ||
| ANAESTHETIC METHOD TYPE FOR DIALYSIS ACCESS CONSTRUCTION | ||
| ANAESTHETIC TYPE FOR JOINT REPLACEMENT | ||
| ANTI CANCER REGIMEN NUMBER | ||
| ARTERIOVENOUS GRAFT MATERIAL TYPE | ||
| ARTHROPLASTY REVISION TYPE | ||
| ARTIFICIAL RUPTURE OF MEMBRANES REASON CODE | ||
| ASA PHYSICAL STATUS CLASSIFICATION SYSTEM CODE | ||
| ASSOCIATED PROCEDURE TYPE FOR ANKLE REPLACEMENT | ||
| BIOLOGICAL RESURFACING TYPE FOR SHOULDER REPLACEMENT | ||
| BIOPSY TYPE FOR CENTRAL NERVOUS SYSTEM TUMOURS | ||
| BLOOD FLOW RATE | ||
| BLOOD TRANSFUSION PRODUCT TYPE | ||
| BLOOD TRANSFUSION TYPE | ||
| BLOOD TRANSFUSION UNITS TRANSFUSED | ||
| BONE GRAFT INDICATION CODE FOR REVISION ANKLE REPLACEMENT | ||
| BONE GRAFT INDICATOR FOR JOINT REPLACEMENT | ||
| BONE GRAFT TYPE FOR REVISION ANKLE REPLACEMENT | ||
| BRACHYTHERAPY TYPE | ||
| BREAST ASSESSMENT OUTCOME | ||
| BREAST SCREENING TEST OUTCOME | ||
| CANCER IMAGING MODALITY | ||
| CANCER IMAGING OUTCOME | ||
| CANCER TREATMENT MODALITY | ||
| CARDIOPULMONARY EXERCISE TEST TYPE | ||
| CHEMICAL THROMBOPROPHYLAXIS REGIME TYPE | ||
| CHEMO RADIATION INDICATOR | ||
| CHEMOTHERAPY ACTUAL DOSE | ||
| CHEST DRAIN IN SITU INDICATOR | ||
| CLINICAL INTERVENTION TYPE | ||
| CLINICAL INVESTIGATION NOT PERFORMED REASON CODE FOR MATERNITY | ||
| CO MORBIDITY ADJUSTMENT INDICATOR | ||
| COMPLICATION TYPE FOR RENAL DIALYSIS ACCESS | ||
| COMPONENT REMOVAL INDICATOR | ||
| CONTINUOUS INFUSION OF PULMONARY VASODILATOR RECEIVED INDICATOR | ||
| CONTINUOUS POSITIVE AIRWAY PRESSURE DELIVERY MODE | ||
| CONTRACEPTION METHOD STATUS | ||
| CYTOLOGY SCREENING ACTION TYPE | ||
| DEINFIBULATION UNDERTAKEN REASON | ||
| DELIVERED IN WATER INDICATOR | ||
| DELIVERY INSTRUMENT TYPE | ||
| DELIVERY OF PLACENTA METHOD | ||
| DIEPOXYBUTANE TEST RESULT | ||
| DRUG ADMINISTRATION DURATION | ||
| DRUG ADMINISTRATION STATUS | ||
| DRUG DAYS SUPPLY | ||
| DRUG DOSAGE AND ADMIN SPECIFICATION | ||
| DRUG IDENTIFICATION | ||
| DRUG INFORMATION COMMENT | ||
| DRUG INFORMATION TYPE | ||
| DRUG QUANTITY SUPPLIED | ||
| DRUG REGIMEN ACRONYM | ||
| DRUG TREATMENT INTENT | ||
| ENDOSCOPIC OR RADIOLOGICAL COMPLICATION TYPE | ||
| ENDOSCOPIC PROCEDURE TYPE | ||
| ENTERAL FEEDING METHOD | ||
| ENTERAL FEED TYPE GIVEN | ||
| EPISIOTOMY PERFORMED REASON CODE | ||
| EXCISION TYPE FOR CENTRAL NERVOUS SYSTEM TUMOURS | ||
| FETAL ORDER | ||
| FIRST DEFINITIVE TREATMENT PROVIDED | ||
| FIXATION TYPE FOR ELBOW OR SHOULDER REPLACEMENT | ||
| FORMULA MILK OR MILK FORTIFIER TYPE | ||
| FRACTION NUMBER | ||
| GERMLINE GENETIC TEST TYPE OFFERED | ||
| HIP SURGERY PATIENT POSITION | ||
| HUMAN PAPILLOMAVIRUS VACCINATION DOSE GIVEN | ||
| IMAGE GUIDED SURGERY INDICATOR | ||
| IMAGING ANATOMICAL SITE | ||
| IMAGING INTERVENTION INDICATOR | ||
| IMAGING MODALITY | ||
| IMAGING OR RADIODIAGNOSTIC EVENT INDICATION CODE FOR RENAL CARE | ||
| INFECTION CULTURE TEST INDICATOR | ||
| INTERVENTION SESSION TYPE FOR STOP SMOKING | ||
| INTERVENTION SETTING TYPE FOR STOP SMOKING | ||
| INTRAPARTUM ANTIBIOTICS GIVEN INDICATOR | ||
| JOINT REPLACEMENT REVISION REASON CODE FOR ANKLE | ||
| JOINT REPLACEMENT REVISION REASON CODE FOR ELBOW | ||
| JOINT REPLACEMENT REVISION REASON CODE FOR HIP | ||
| JOINT REPLACEMENT REVISION REASON CODE FOR KNEE | ||
| JOINT REPLACEMENT REVISION REASON CODE FOR SHOULDER | ||
| KIDNEY TRANSPLANTED CODE | ||
| LABOUR FIRST STAGE LENGTH | ||
| LABOUR OR DELIVERY ONSET METHOD | ||
| LABOUR SECOND STAGE LENGTH | ||
| LAPAROTOMY FOR NECROTISING ENTEROCOLITIS INDICATION CODE | ||
| LIVER CANCER SURVEILLANCE SCAN INDICATOR | ||
| LIVER SURGERY PERFORMED TYPE | ||
| LIVER TRANSARTERIAL EMBOLISATION MATERIAL INJECTION TYPE | ||
| LIVER TRANSARTERIAL EMBOLISATION OF HEPATOCELLULAR CARCINOMA INDICATOR | ||
| LONG HEAD BICEPS TENOTOMY INDICATOR | ||
| MARGIN INVOLVED INDICATION CODE | ||
| MECHANICAL THROMBOPROPHYLAXIS REGIME TYPE | ||
| MINIMALLY INVASIVE SURGERY INDICATOR | ||
| MORE THAN THREE RECTAL WASHOUTS RECEIVED INDICATOR | ||
| NEOADJUVANT THERAPY INDICATOR | ||
| NEONATAL RESUSCITATION METHOD | ||
| NEONATAL RESUSCITATION METHOD FOR NATIONAL NEONATAL DATA SET | ||
| NEPHRECTOMY TYPE | ||
| NEURODEVELOPMENTAL ASSESSMENT ALREADY TAKEN INDICATOR | ||
| NEWBORN HEARING INCOMPLETE REASON CODE | ||
| NEWBORN HEARING SCREENING TEST TYPE | ||
| NITRIC OXIDE GIVEN INDICATOR | ||
| NUMBER OF TELETHERAPY FIELDS | ||
| OBSERVATION SCHEME IN USE | ||
| OPPORTUNISTIC SCREENING TYPE | ||
| PAIN RELIEF TYPE IN LABOUR AND DELIVERY | ||
| PARENTAL CONSENT TO ADMINISTER VITAMIN K INDICATOR | ||
| PARENTAL CONSENT TO POST MORTEM INDICATOR | ||
| PARENTERAL NUTRITION RECEIVED INDICATOR | ||
| PATHOLOGY INVESTIGATION PRIORITY | ||
| PATHOLOGY RESULT REPORTED DATE | ||
| PATIENT PROCEDURE PERFORMED INDICATOR | ||
| PATIENT PROCEDURE TYPE FOR PRIMARY ANKLE REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR PRIMARY ELBOW REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR PRIMARY HIP REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR PRIMARY KNEE REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR PRIMARY SHOULDER REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR REVISION ANKLE REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR REVISION ELBOW REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR REVISION HIP REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR REVISION KNEE REPLACEMENT | ||
| PATIENT PROCEDURE TYPE FOR REVISION SHOULDER REPLACEMENT | ||
| PATIENT SPECIFIC INSTRUMENTS INDICATOR FOR KNEE REPLACEMENT | ||
| PATIENT TREATED TO CHILDRENS CANCER AND LEUKAEMIA GROUP GUIDELINES INDICATOR | ||
| PERITONEAL DIALYSIS CATHETER INSERTION TECHNIQUE | ||
| PERITONEAL DIALYSIS CATHETER TYPE | ||
| PERITONEAL DIALYSIS TREATMENT REGIME | ||
| PLANE OF SURGICAL EXCISION TYPE | ||
| PLANNED TREATMENT CHANGE REASON | ||
| POST MORTEM CARRIED OUT INDICATOR | ||
| POST MORTEM CONFIRMED NECROTISING ENTEROCOLITIS DIAGNOSIS INDICATOR | ||
| POST MORTEM TYPE | ||
| PRETREATMENT PROSTATE BIOPSY TECHNIQUE TYPE | ||
| PREVIOUS BONY INFECTION INDICATOR OF TIBIA OR HINDFOOT | ||
| PREVIOUS FRACTURE INDICATOR FOR ANKLE REPLACEMENT | ||
| PREVIOUS SURGERY TYPE FOR ANKLE JOINT | ||
| PREVIOUS SURGERY TYPE FOR SHOULDER REPLACEMENT | ||
| PRIMARY INDUCTION CHEMOTHERAPY FAILURE INDICATOR | ||
| PRINCIPAL DIAGNOSTIC IMAGING TYPE | ||
| PROCEDURE RENAL DIALYSIS ACCESS REPAIR OR REVISION TYPE | ||
| PROCEDURE SCHEME IN USE | ||
| PROCEDURE SIDE RENAL DIALYSIS ACCESS CONSTRUCTION CODE | ||
| PROCEDURE SITE RENAL DIALYSIS ACCESS CONSTRUCTION CODE | ||
| PROSTATE NERVE SPARING SURGERY TYPE | ||
| RADICAL PROSTATECTOMY MARGIN STATUS | ||
| RADIOISOTOPE | ||
| RADIOTHERAPY ACTUAL DOSE | ||
| RADIOTHERAPY BEAM TYPE | ||
| RADIOTHERAPY PRESCRIBED DOSE | ||
| RADIOTHERAPY TREATMENT MODALITY | ||
| REGIONAL ANAESTHETIC TECHNIQUE FOR CANCER | ||
| RELAPSE METHOD DETECTION TYPE | ||
| REMOVAL REASON TYPE FOR DIALYSIS ACCESS | ||
| RENAL DIALYSIS ACCESS TYPE | ||
| RENAL TRANSPLANT FAILURE CAUSE CODE | ||
| RENAL TREATMENT MODALITY CHANGE REASON CODE | ||
| RENAL TREATMENT MODALITY CODE | ||
| RENAL TREATMENT PRIMARY SUPERVISION CODE | ||
| REPLOGLE TUBE IN SITU INDICATOR | ||
| RESPIRATORY SUPPORT DEVICE TYPE FOR NATIONAL NEONATAL DATA SET | ||
| RESPIRATORY SUPPORT MODE FOR NATIONAL NEONATAL DATA SET | ||
| RESTRICTIVE INTERVENTION TYPE | ||
| RESULT SENT DIRECT | ||
| RETINOPATHY OF PREMATURITY SCREENING OUTCOME STATUS CODE | ||
| REVISION PROCEDURE TYPE FOR ANKLE OR KNEE REPLACEMENT | ||
| REVISION PROCEDURE TYPE FOR ELBOW OR SHOULDER REPLACEMENT | ||
| REVISION PROCEDURE TYPE FOR HIP REPLACEMENT | ||
| ROTATOR CUFF CONDITION | ||
| RUPTURE OF MEMBRANES METHOD | ||
| SARCOMA SURGICAL MARGIN | ||
| SENTINEL LYMPH NODE BIOPSY TYPE | ||
| SIGNIFICANT MATERNAL PYREXIA IN LABOUR INDICATOR | ||
| STEM CELL INFUSION DONOR TYPE | ||
| STEM CELL INFUSION SOURCE CODE | ||
| STEM CELL TRANSPLANT CONDITIONING REGIMEN | ||
| STEROIDS GIVEN DURING PREGNANCY TO MATURE FETAL LUNGS INDICATOR | ||
| STOMA PRESENT INDICATOR | ||
| SURFACTANT GIVEN INDICATOR | ||
| SURGICAL ACCESS TYPE | ||
| SURGICAL APPROACH FOR PRIMARY HIP REPLACEMENT | ||
| SURGICAL APPROACH FOR PRIMARY KNEE REPLACEMENT | ||
| SURGICAL APPROACH FOR PRIMARY OR REVISION ANKLE REPLACEMENT | ||
| SURGICAL APPROACH FOR PRIMARY OR REVISION ELBOW REPLACEMENT | ||
| SURGICAL APPROACH FOR PRIMARY OR REVISION SHOULDER REPLACEMENT | ||
| SURGICAL APPROACH FOR REVISION HIP REPLACEMENT | ||
| SURGICAL APPROACH FOR REVISION KNEE REPLACEMENT | ||
| SURGICAL COMPLICATION TYPE | ||
| SURGICAL PALLIATION TYPE | ||
| SURVEILLANCE TECHNIQUE DIALYSIS TYPE | ||
| SYSTEMIC ANTI CANCER THERAPY DRUG ROUTE OF ADMINISTRATION | ||
| SYSTEMIC ANTI CANCER THERAPY PROGRAMME NUMBER | ||
| SYSTEMIC ANTI CANCER THERAPY REGIMEN MODIFICATION INDICATOR | ||
| TRACHEOSTOMY TUBE IN SITU INDICATOR | ||
| TREATMENT TYPE FOR NECROTISING ENTEROCOLITIS | ||
| TREATMENT TYPE FOR PATENT DUCTUS ARTERIOSUS | ||
| UNTOWARD INTRAOPERATIVE EVENT CODE FOR ANKLE REPLACEMENT | ||
| UNTOWARD INTRAOPERATIVE EVENT CODE FOR ELBOW REPLACEMENT | ||
| UNTOWARD INTRAOPERATIVE EVENT CODE FOR HIP REPLACEMENT | ||
| UNTOWARD INTRAOPERATIVE EVENT CODE FOR KNEE REPLACEMENT | ||
| UNTOWARD INTRAOPERATIVE EVENT CODE FOR SHOULDER REPLACEMENT | ||
| VASCULAR LINE TYPE IN SITU | ||
| VISUAL INSPECTION CONFIRMED NECROTISING ENTEROCOLITIS DURING LAPAROTOMY INDICATOR | ||
| VITAMIN K ADMINISTERED INDICATOR | ||
| VITAMIN K ROUTE OF ADMINISTRATION |
Change to Class: Changed Description
A period of time within a Hospital Provider Spell during which a PATIENT receives critical care.
For PATIENTS treated in 'neonatal facilities', that is, in WARDS with a CRITICAL CARE UNIT FUNCTION of 13, 14 or 15, critical care PATIENTS include:
a) All PATIENTS on a WARD with a CRITICAL CARE UNIT FUNCTION Neonatal Intensive Care Unit regardless of care being delivered.
or
b) All PATIENTS (excluding Mothers) on a WARD with a CRITICAL CARE UNIT FUNCTION Facility for Babies on a Neonatal Transitional Care Ward or Facility for Babies on a Maternity Ward to whom one or more CRITICAL CARE ACTIVITIES with codes 01 to 02, 04 - 16 or 22 - 29 is delivered for a period greater than 4 hours.
For PATIENTS treated in 'adult facilities' or 'other facilities', that is, WARDS with a CRITICAL CARE UNIT FUNCTION of 01-03, 05-12, 90 or 91, the following conditions apply:
- A new CRITICAL CARE PERIOD starts when the PATIENT is admitted to a critical care location regardless of CRITICAL CARE LEVEL.
- Outreach activity, although part of critical care, should not be recorded as a CRITICAL CARE PERIOD.
- Resuscitation conducted outside designated critical care locations, e.g. as part of conventional care in operating theatres and Accident and Emergency Departments, should not be recorded as a CRITICAL CARE PERIOD even though many aspects of the care given may satisfy the definitions for Level 2 or Level 3 CRITICAL CARE LEVELS.
- Repeated admissions to the same unit should be recorded as separate CRITICAL CARE PERIODS identified by different CRITICAL CARE START DATES. A transfer to a different critical care location within the same Hospital Provider Spell will initiate a new CRITICAL CARE PERIOD identified by the differing CRITICAL CARE UNIT FUNCTION.
- A change of Consultant Episode (Hospital Provider) or brief transfers for investigation and/or treatment do not end the CRITICAL CARE PERIOD.
- A CRITICAL CARE PERIOD ends when the PATIENT is discharged from the critical care location, or dies, or the care that is being delivered in a non-standard location (see below) is CRITICAL CARE LEVEL National Code 00 Level 0 or 01 'Level 1'.
- Critical care locations are described by CRITICAL CARE UNIT FUNCTION and UNIT BED CONFIGURATION. Critical Care beds may include occasional non-standard locations using a ward area or operating department when conventional critical care beds are not available. Non standard locations may only be recorded if the CRITICAL CARE LEVEL is National Code 02 'Level 2' or 03 'Level 3' and the delivery of care is greater than four hours. For CRITICAL CARE PERIODS with CRITICAL CARE UNIT FUNCTIONS of either National Code 90 'non standard location using a ward area' or National Code 91 'non standard location using the operating department', care provided in these locations must exceed four hours, and must include CLINICAL INTERVENTIONS, monitoring and supervision normally associated with a critical care area i.e. intensive therapy unit or high dependency unit. Further the care provided must be continuously supervised by currently practising critical care doctors and NURSES who would normally work in critical care.
- The type of ORGAN SYSTEM SUPPORTED is recorded and the duration of each organ system support is calculated from the ACTIVITY PROPERTY EFFECTIVE DATE and the ACTIVITY PROPERTY END DATE.
- A CRITICAL CARE PERIOD does not include the following:
a. Surgical and anaesthetic intra-operative care
b. Post-operative care within an operating department except where level 2 or level 3 care are provided for more than 4 hours
c. Care delivered in a cardiac or coronary care unit
d. Imaging procedures
e. Endoscopy procedures
f. Care delivered in an Accident and Emergency Department
Commissioning Data Set Transmission
- The CRITICAL CARE PERIOD may overlap Episodes, i.e. the CRITICAL CARE START DATE may precede the start of the CONSULTANT/ MIDWIFE / NURSE Episode; similarly the CRITICAL CARE PERIOD may not have ended by the end of the Episode.
- The Data Elements CRITICAL CARE START DATE, CRITICAL CARE LOCAL IDENTIFIER and CRITICAL CARE UNIT FUNCTION must always be present.
- Where applicable, Support Days and Critical Care Level Days should only be entered when the CRITICAL CARE PERIOD is finished and the CRITICAL CARE DISCHARGE DATE is entered.
- The CRITICAL CARE DISCHARGE DATE must be on or before the DISCHARGE DATE (HOSPITAL PROVIDER SPELL).
Change to Class: Changed Attributes
| ADULT COMORBIDITY EVALUATION 27 SCORE | ||
| CHILD PUGH SCORE | ||
| EUROPEAN GROUP FOR THE IMMUNOLOGICAL CLASSIFICATION OF LEUKAEMIA SCORING SYSTEM SCORE | ||
| PERSON SCORE |
Change to Class: Changed Attributes
| K | REFERRAL TO TREATMENT PERIOD START DATE | |
| REFERRAL TO TREATMENT PERIOD END DATE | ||
| REFERRAL TO TREATMENT PERIOD STATUS |
Change to Attribute: Changed Description
The type of ASSESSMENT TOOL.
National Codes:
Change to Attribute: Changed status to Retired, Name, Description
A coded representation of the score ranges defined for the Children's Global Assessment Scale.This item has been retired from the NHS Data Model and Dictionary.
National Codes:The last live version of this item is available in the March 2018 release of the NHS Data Model and Dictionary.
Change to Attribute: Changed status to Retired, Name, Description
- Retired CHILDRENS GLOBAL ASSESSMENT SCALE SCORE RANGE CODE
- Changed Name from Data_Dictionary.Attributes.C.Ce.CHILDRENS_GLOBAL_ASSESSMENT_SCALE_SCORE_RANGE_CODE to Retired.Data_Dictionary.Attributes.C.CHILDRENS_GLOBAL_ASSESSMENT_SCALE_SCORE_RANGE_CODE
- Changed Description
Change to Attribute: Changed Description
CONSULTATION MEDIUM USED identifies the communication mechanism used to relay information between the CARE PROFESSIONAL and the PERSON who is the subject of the consultation, during a CARE ACTIVITY.
The telephone or telemedicine consultation should directly support diagnosis and care planning and must replace a face to face Out-Patient Attendance Consultant, Clinic Attendance Nurse or Clinic Attendance Midwife, types of CARE ACTIVITY. A record of the telephone or telemedicine consultation must be retained in the PATIENT's records.
Telephone contacts solely for informing PATIENTS of results are excluded.
National Codes:
| 01 | Face to face communication |
| 02 | Telephone |
| 03 | Telemedicine web camera |
| 04 | Talk type for a PERSON unable to speak |
| 05 | Email ** |
| 06 | Short Message Service (SMS) - Text Messaging *** |
| 98 | Other * |
Notes:
- * National Code 98 'Other' is only used for the Community Services Data Set, Mental Health Services Data Set and Sexual and Reproductive Health Activity Data Set. It is NOT valid in any other data set including Commissioning Data Set version 6-2.
** National Codes 05 'Email' and 06 'Short Message Service (SMS) - Text Messaging' areNOTvalid for Commissioning Data Set version 6-2.** National Code 06 'Short Message Service (SMS) - Text Messaging' isNOTvalid for theHIV and AIDS Reporting Data Set.- ** National Codes 05 'Email' is NOT valid for Commissioning Data Set version 6-2.
- *** National Code 06 'Short Message Service (SMS) - Text Messaging' is NOT valid for Commissioning Data Set version 6-2 and the HIV and AIDS Reporting Data Set.
Change to Attribute: Changed Description
The code to identify the serum Tumour markers (measurable biochemicals associated with a malignancy of Tumour CELLS) for testicular cancer only.
This is derived following recording of the biochemistry test items:
S CATEGORY (LACTATE DEHYDROGENASE)- S CATEGORY (LACTATE DEHYDROGENASE) (LDH)
- S CATEGORY (HUMAN CHORIONIC GONADOTROPIN) (HCG)
- S CATEGORY (ALPHA FETOPROTEIN) (AFP)
National Codes:
| CODE | LDH (UNITS/LITRE) | HCG (MILLIUNITS/MILLILITRE) | AFP (NANOGRAMS/MILLILITRE) |
| SX | Marker studies not available or not performed | Marker studies not available or not performed | Marker studies not available or not performed |
| S0 | Normal | Normal | Normal |
| S1 | Less than 1.5 x normal | Less than 5,000 | Less than 1,000 |
| S2 | 1.5-10 x normal | 5,000-50,000 | 1,000-10,000 |
| S3 | Greater than 10 x normal | Greater than 50,000 | Greater than 10,000 |
Change to Attribute: Changed Name
- Changed Name from Data_Dictionary.Attributes.S.Smo.SOCIO-ECONOMIC_CLASSIFICATION_CODE_FOR _STOP_SMOKING to Data_Dictionary.Attributes.S.Smo.SOCIO-ECONOMIC_CLASSIFICATION_CODE_FOR_STOP_SMOKING
Change to Data Element: Changed Description
| Format/Length: | an3 |
| National Codes: | See TREATMENT FUNCTION CODE |
| Default Codes: | 199 - Non-UK provider; TREATMENT FUNCTION not known, treatment mainly surgical |
| 499 - Non-UK provider; TREATMENT FUNCTION not known, treatment mainly medical |
Notes:
ACTIVITY TREATMENT FUNCTION CODE is the same as attribute TREATMENT FUNCTION CODE.
The default codes 199 and 499 are only applicable for overseas health care providers.
ACTIVITY TREATMENT FUNCTION CODE is used by the Secondary Uses Service to derive the Healthcare Resource Group 4. Failure to correctly populate this data element is likely to result in an incorrect Healthcare Resource Group, usually associated with lower levels of healthcare resource.
For further information, please refer to the NHS Digital website at: Payment by Results Guidance.
Change to Data Element: Changed Description
| Format/Length: | an3 |
| National Codes: | See TREATMENT FUNCTION CODE |
| Default Codes: |
Notes:
ACTIVITY TREATMENT FUNCTION CODE (DECISION TO ADMIT) is the same as attribute TREATMENT FUNCTION CODE.
ACTIVITY TREATMENT FUNCTION CODE (DECISION TO ADMIT) is the TREATMENT FUNCTION CODE of the SERVICE to which a PATIENT is to be admitted.
Change to Data Element: Changed Description
| Format/Length: | an1 |
| National Codes: | |
| Default Codes: |
Notes:
A code to determine the format of the associated PATIENT USUAL ADDRESS data.
This is necessary whenever an address is included in a CDS message to allow correct interpretation by the recipient. The following values have been used in many CDS message implementations and are recommended to be used.
Permitted National Codes:
| 1 or S | To denote a "Label format" address, i.e. an address consisting of up to five address lines of 35 characters where each line is left justified as a specific data element |
| 2 or U | To denote an unstructured address, i.e. an address consisting of up to five contiguous data elements of 35 characters representing a 175 character string |
Change to Data Element: Changed Description
| Format/Length: | max an2 |
| National Codes: | See PERSON BLOOD GROUP |
| Default Codes: |
Notes:
BLOOD GROUP ABO CLASSIFICATION is the same as attribute PERSON BLOOD GROUP.
Change to Data Element: Changed Description
| Format/Length: | an3 |
| National Codes: | See PERSON RHESUS FACTOR |
| Default Codes: |
Notes:
BLOOD RHESUS CLASSIFICATION is the same as attribute PERSON RHESUS FACTOR.
Change to Data Element: Changed Description
| Format/Length: | an2 |
| National Codes: | See BRACHYTHERAPY TYPE |
| Default Codes: |
Notes:
BRACHYTHERAPY TYPE is the same as attribute BRACHYTHERAPY TYPE.
Change to Data Element: Changed Description
| Format/Length: | max an70 |
| National Codes: | |
| Default Codes: |
Notes:
DEATH CAUSE COMMENT is the same as attribute DEATH CAUSE COMMENT.
Change to Data Element: Changed Description
| Format/Length: | n3 |
| National Codes: | |
| Default Codes: | 998 - 998 or more days of dermatological support |
| 999 - occurred but day count not known |
Notes:
The total number of days that the PATIENT received dermatological system support during a CRITICAL CARE PERIOD, ranging from 000 to 997 days.
This is derived from the difference between the ACTIVITY PROPERTY EFFECTIVE DATE and the ACTIVITY PROPERTY END DATE for all ACTIVITY PROPERTIES where the ORGAN SYSTEM SUPPORTED is National Code 08 'Dermatological Support' within the CRITICAL CARE PERIOD.
DERMATOLOGICAL SUPPORT DAYS is used by the Secondary Uses Service to derive the Healthcare Resource Group 4. Failure to correctly populate this data element is likely to result in an incorrect Healthcare Resource Group, usually associated with lower levels of healthcare resource.
For further information, please refer to the NHS Digital website at: Payment by Results Guidance.
Change to Data Element: Changed Name
- Changed Name from Data_Dictionary.Data_Field_Notes.D.Diag.DIAGNOSIS_(ICD_RECORDED_ON_ DISCHARGE_FROM_NEONATAL_CRITICAL_CARE) to Data_Dictionary.Data_Field_Notes.D.Diag.DIAGNOSIS_(ICD_RECORDED_ON_DISCHARGE_FROM_NEONATAL_CRITICAL_CARE)
Change to Data Element: Changed Description
| Format/Length: | character 6 |
| National Codes: | |
| Default Codes: |
Notes:
The time band for reporting on Diagnostics Waiting Times and Activity Data Set and Diagnostics Waiting Times Census Data Set.
For monthly reporting of diagnostic waiting times and activity:
Permitted National Codes:
| 00-<01 | less than 1 week |
| 01-<02 | 1 to less than 2 weeks |
| 02-<03 | 2 weeks to less than 3 weeks |
| 03-<04 | 3 weeks to less than 4 weeks |
| 04-<05 | 4 weeks to less than 5 weeks |
| 05-<06 | 5 weeks to less than 6 weeks |
| 06-<07 | 6 weeks to less than 7 weeks |
| 07-<08 | 7 weeks to less than 8 weeks |
| 08-<09 | 8 weeks to less than 9 weeks |
| 09-<10 | 9 weeks to less than 10 weeks |
| 10-<11 | 10 weeks to less than 11 weeks |
| 11-<12 | 11 weeks to less than 12 weeks |
| 12-<13 | 12 weeks to less than 13 weeks |
| 13+ | 13 weeks or more |
For the diagnostic waiting times census:
Permitted National Codes:
| 06-<13 | 6 weeks to less than 13 weeks |
| 13+ | 13 weeks or more |
Change to Data Element: Changed Description
| Format/Length: | an2 |
| National Codes: | See PERSON BLOOD GROUP |
| Default Codes: |
Notes:
DONOR BLOOD GROUP ABO CLASSIFICATION is the same as attribute PERSON BLOOD GROUP.
Change to Data Element: Changed Description
| Format/Length: | an3 |
| National Codes: | See PERSON RHESUS FACTOR |
| Default Codes: |
Notes:
DONOR BLOOD RHESUS CLASSIFICATION is the same as attribute PERSON RHESUS FACTOR.
Change to Data Element: Changed Description
| Format/Length: | n5 |
| National Codes: | |
| Default Codes: | 99998 - Not applicable (i.e. psychiatric patient not detained, included in census only because of long stay status) |
| 99999 - Not known (i.e. cannot be derived because one or more dates are unavailable): a validation error |
Notes:
DURATION OF DETENTION is the duration derived from the DATE DETENTION COMMENCED and the date of the census.
Enter 00000-29200 in days (approximately 80 years), right justified with preceding zeros.
Change to Data Element: Changed Description
| Format/Length: | n4 |
| National Codes: | |
| Default Codes: | 9998 - Not applicable |
| 9999 - Not known (i.e. no date known for decision to admit): a validation error |
Notes:
DURATION OF ELECTIVE WAIT is a derived item that records the waiting time from the ORIGINAL DECIDED TO ADMIT DATE to the admission date at the provider where the treatment actually takes place.
Enter 0000-8887 in days, right justified with preceding zeros.
A waiting time of 0 (zero) days is only to be entered after careful scrutiny.
Please note that the PATIENT's WAITING PERIOD EXCLUSIONS (their aggregate suspended and/or self-deferred periods) should be subtracted from the DURATION OF ELECTIVE WAIT.
Change to Data Element: Changed Description
| Format/Length: | See DATE |
| National Codes: | |
| Default Codes: |
Notes:
END DATE (RENAL TREATMENT MODALITY) is the End Date of the RENAL TREATMENT MODALITY CODE.
Change to Data Element: Changed Description
| Format/Length: | n2 |
| National Codes: | |
| Default Codes: | 98 - Not applicable |
| 99 - Not known: a validation error |
Notes:
EPISODE NUMBER is the same as attribute ACTIVITY IDENTIFIER and is used to uniquely identify episodes, and is a sequence number for each Consultant Episode (Hospital Provider) in a Hospital Provider Spell. The first episode of each new Hospital Provider Spell (including re-admitted PATIENTS) commences at 01.
A known EPISODE NUMBER can be between 01 to 87.
For other Health Care Provider episodes, it is a sequence number for a CONSULTANT/PATIENT combination; or it is a sequence number for each Sexual Health and HIV Episode.
EPISODE NUMBER is used by the Secondary Uses Service to derive the Healthcare Resource Group 4. Failure to correctly populate this data element is likely to result in an incorrect Healthcare Resource Group, usually associated with lower levels of healthcare resource.
For further information, please refer to the NHS Digital website at: Payment by Results Guidance.
Change to Data Element: Changed Description
| Format/Length: | n6 |
| National Codes: | |
| Default Codes: |
Notes:
The total number of cancelled operations where the national standard (treatment within 28 days following an operation cancellation by the hospital) has been breached.
The total number of OFFERS OF ADMISSION with an OPERATION CANCELLATION National Code 1 'Operation cancelled for non-clinical reasons on the day of surgery' or National Code 2 'Operation cancelled at short notice for non-clinical reasons although not on the day of surgery', where, for the ELECTIVE ADMISSION LIST ENTRY, there was either:
no subsequent OFFER OF ADMISSION with an OFFERED FOR ADMISSION DATE (to come in date) within 28 days of the original OFFER OF ADMISSION
or
there was a subsequent OFFER OF ADMISSION with an OFFERED FOR ADMISSION DATE (to come in date) within 28 days of the original OFFER OF ADMISSION but one which resulted in another OPERATION CANCELLATION National Code 1 'Operation cancelled for non-clinical reasons on the day of surgery' or National Code 2 'Operation cancelled at short notice for non-clinical reasons although not on the day of surgery' or an the ADMISSION OFFER OUTCOME of National Code 6 Admission cancelled by hospital before day offered for admission.
Change to Data Element: Changed Description
| Format/Length: | n3 |
| National Codes: | |
| Default Codes: | 998 - 998 or more days of gastro-intestinal support |
| 999 - occurred but day count not known |
Notes:
The total number of days that the PATIENT received gastro-intestinal system support during a CRITICAL CARE PERIOD, ranging from 000 to 997 days.
This is derived from the difference between the ACTIVITY PROPERTY EFFECTIVE DATE and the ACTIVITY PROPERTY END DATE for all ACTIVITY PROPERTIES where the ORGAN SYSTEM SUPPORTED is National Code 07 'Gastrointestinal Support' within the CRITICAL CARE PERIOD.
Change to Data Element: Changed Description
| Format/Length: | n6 |
| National Codes: | |
| Default Codes: |
Notes:
The total number of OFFERS OF ADMISSION where the indicator OPERATION CANCELLATION is National Code 1 'Operation cancelled for non-clinical reasons on the day of surgery' or National Code 2 'Operation cancelled at short notice for non-clinical reasons although not on the day of surgery'.
Change to Data Element: Changed Description
| Format/Length: | n1 |
| National Codes: | |
| Default Codes: | 9 - Not known: a validation error |
Notes:
This is used in the CDS to identify the format of a PATIENT NAME, with the classification values indicating whether it is a PERSON NAME STRUCTURED or PERSON NAME UNSTRUCTURED.
Permitted National Codes:
| 1 | Structured - two element name, forename followed by surname, each element an35 |
| 2 | Unstructured - an70 |
Change to Data Element: Changed Description
| Format/Length: | n2 |
| National Codes: | |
| Default Codes: |
Notes:
The maximum number of ORGAN SYSTEMS SUPPORTED on any one day during a CRITICAL CARE PERIOD. Each organ system can only be counted once on any calendar day. Both basic and advanced categories cannot be counted at the same time. The number of organ systems supported can be between 00 to 07, although for the purposes of recording on the Commissioning Data Set messages Gastro-intestinal support days are not recorded so the maximum is effectively 06.
This is derived by counting the maximum number of ACTIVITY PROPERTIES where the ORGAN SYSTEM SUPPORTED is different, for each day of the CRITICAL CARE PERIOD and reporting the highest number. Each ACTIVITY PROPERTY will have one or more ACTIVITY PROPERTY EFFECTIVE DATES and ACTIVITY PROPERTY END DATES within the CRITICAL CARE PERIOD. Both basic and advanced categories cannot be counted at the same time therefore the maximum number of systems supported is 7.
Change to Data Element: Changed Description
| Format/Length: | max an70 |
| National Codes: | |
| Default Codes: |
Notes:
PATIENT NAME is the PERSON NAME where the PERSON NAME CLASSIFICATION is 'Preferred Name' of the PATIENT.
NAME FORMAT CODE indicates whether it is a PERSON NAME STRUCTURED or PERSON NAME UNSTRUCTURED.
The PATIENT's name and address should be withheld from any commissioning data that contains a valid NHS NUMBER. See Security Issues and Patient Confidentiality for more details.
Change to Data Element: Changed Description
| Format/Length: | an1 |
| National Codes: | See PATIENT SPECIFIC INSTRUMENTS INDICATOR FOR KNEE REPLACEMENT |
| Default Codes: |
Notes:
PATIENT SPECIFIC INSTRUMENTS INDICATOR (KNEE REPLACEMENT) is the same as attribute PATIENT SPECIFIC INSTRUMENTS INDICATOR FOR KNEE REPLACEMENT.
Change to Data Element: Changed Description
| Format/Length: | n6 |
| National Codes: | |
| Default Codes: |
Notes:
PATIENTS WAITING FOR DIAGNOSTIC TEST is the number of PATIENTS that have been waiting for a time within a DIAGNOSTICS REPORTING TIME BAND for the particular test or investigation.
PATIENTS WAITING FOR DIAGNOSTIC TEST is derived from the SERVICE REQUEST DATE of the SERVICE REQUEST to the REPORTING PERIOD END DATE or the APPOINTMENT DATE of the last missed APPOINTMENT (if reset due to missed or cancelled APPOINTMENT where ATTENDED OR DID NOT ATTEND are codes 2 Appointment cancelled by, or on behalf of, the PATIENT, 3 Did not attend - no advance warning given or 7 PATIENT arrived late and could not be seen) to the REPORTING PERIOD END DATE.
For pathology diagnostic tests, the total waiting time is measured from the SERVICE REQUEST DATE to the INVESTIGATION RESULT DATE. For other diagnostic test waiting times, it is measured from the SERVICE REQUEST DATE to the Clinical Intervention Date of the CLINICAL INTERVENTION.
Change to Data Element: Changed Description
| Format/Length: | an2 |
| National Codes: | See PATIENT TRIAL STATUS FOR CANCER |
| Default Codes: | 09 - Not Known (Not Recorded) |
Notes:
PATIENT TRIAL STATUS (CANCER) is the same as attribute PATIENT TRIAL STATUS FOR CANCER.
Change to Data Element: Changed Description
| Format/Length: | max an8 |
| NWDS ID: | SPOC |
| NWDS Field Name: | Post Code |
| National Codes: | |
| Default Codes: |
Notes:
POSTCODE is the same as attribute POSTCODE.
For further information on POSTCODES, see:
- NHS Digital website at: ODS postcode files.
If a POSTCODE is not known, (for example, the PATIENT has no fixed abode, the PATIENT is an Overseas Visitor etc.) the appropriate Organisation Data Service pseudo POSTCODE should be used. The pseudo POSTCODES can be found on the Organisation Data Service pages of the NHS Digital website at: Office of National Statistics data: Country names and Pseudo country postcodes.
Change to Data Element: Changed Description
| Format/Length: | n6 |
| National Codes: | |
| Default Codes: |
Notes:
For PATIENTS with no DECISION TO ADMIT for treatment, REFERRAL TO TREATMENT PERIOD INCOMPLETE WITHIN TIMEBAND NUMBER (NON-ADMITTED PATIENTS) is the number of REFERRAL TO TREATMENT PERIODS during the REPORTING PERIOD with no REFERRAL TO TREATMENT PERIOD END DATE, reported by REFERRAL TO TREATMENT PERIOD BREACH TIME BAND.
That is, for PATIENTS with no DECISION TO ADMIT for treatment, the number of REFERRAL TO TREATMENT PERIODS where there is either:
| a. | no future APPOINTMENT for a PLANNED ACTIVITY where the planned ACTIVITY has a REFERRAL TO TREATMENT PERIOD STATUS of 30 | ||
OR | |||
| b. | a future APPOINTMENT for a PLANNED ACTIVITY where the planned ACTIVITY has a REFERRAL TO TREATMENT PERIOD STATUS of 30, but the APPOINTMENT DATE is not before the REFERRAL TO TREATMENT PERIOD BREACH DATE. | ||
Change to Data Element: Changed Description
| Format/Length: | an2 |
| National Codes: | See SENTINEL LYMPH NODE BIOPSY TYPE |
| Default Codes: |
Notes:
SENTINEL NODE PROCEDURE is the same as attribute SENTINEL LYMPH NODE BIOPSY TYPE.
Change to Data Element: Changed Description
| Format/Length: | min an5 max an9 |
| National Codes: | |
| Default Codes: | ZZ201 - Not applicable (intended to deliver at home) |
| ZZ888 - Not Applicable (intended to deliver at non-NHS Organisation) | |
| ZZ203 - Not known (intended place of delivery not known) |
Notes:
SITE CODE (OF INTENDED PLACE OF DELIVERY) is the same as attribute ORGANISATION SITE CODE
SITE CODE (OF INTENDED PLACE OF DELIVERY) is the ORGANISATION SITE CODE of the Organisation that is the intended place of delivery of the baby as part of a Maternity Episode.
SITE CODE (OF INTENDED PLACE OF DELIVERY) will be replaced with ORGANISATION SITE IDENTIFIER (OF INTENDED PLACE OF DELIVERY), when it has been approved for use in national information standards.
Change to Data Element: Changed Description
| Format/Length: | an1 |
| National Codes: | See SPECIMEN NATURE |
| Default Codes: | 9 - Not Known (Not recorded or test not done) |
Notes:
SPECIMEN NATURE is the same as attribute SPECIMEN NATURE.
Change to Data Element: Changed Description
| Format/Length: | See DATE |
| National Codes: | |
| Default Codes: |
Notes:
START DATE (RENAL TREATMENT MODALITY) is the same as attribute ACTIVITY DATE where ACTIVITY DATE TYPE is National Code 'Start Date' for the renal treatment modality.
Change to Data Element: Changed Description
| Format/Length: | max n6 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING LOST TO FOLLOW-UP TOTAL (PREGNANT WOMEN) is the number of pregnant women in a REPORTING PERIOD who have a Person Stop Smoking Episode and an OUTCOME AT 4 WEEK FOLLOW-UP FOR STOP SMOKING of National Code 'Non-smoking status not known/lost to follow-up'.
Change to Data Element: Changed Description
| Format/Length: | max n6 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING NOT QUIT TOTAL (PREGNANT WOMEN) is the number of pregnant women in a REPORTING PERIOD who have a Person Stop Smoking Episode and an OUTCOME AT 4 WEEK FOLLOW-UP FOR STOP SMOKING of National Code 'Not quit at 4 week follow-up'.
Change to Data Element: Changed Description
| Format/Length: | max n8 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING SERVICE CUMULATIVE SPEND is the same as attribute FINANCIAL AMOUNT, where the FINANCIAL ALLOCATION OR SPEND TYPE FOR STOP SMOKING is National Code 'Cumulative spend for the financial year (excluding pharmacotherapies)'.
For guidance on how to calculate this, see the NHS Digital website at: NHS Stop Smoking Services Guidance Part 2 2016-17.
Change to Data Element: Changed Description
| Format/Length: | max n8 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING SERVICE LOCAL AUTHORITY FINANCIAL ALLOCATION is the same as attribute FINANCIAL AMOUNT, where the FINANCIAL ALLOCATION OR SPEND TYPE FOR STOP SMOKING is National Code 'Total financial allocation to Local Authorities for the financial year (excluding pharmacotherapies)'.
For guidance on how to calculate this, see the NHS Digital website at: NHS Stop Smoking Services Guidance Part 2 2016-17.
Change to Data Element: Changed Description
| Format/Length: | max n8 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING SERVICE OTHER FINANCIAL ALLOCATION is the same as attribute FINANCIAL AMOUNT, where the FINANCIAL ALLOCATION OR SPEND TYPE FOR STOP SMOKING is National Code 'Other financial allocation including any underspend carried over from the previous financial year'.
For guidance on how to calculate this, see the NHS Digital website at: NHS Stop Smoking Services Guidance Part 2 2016-17.
Change to Data Element: Changed Description
| Format/Length: | max n8 |
| National Codes: | |
| Default Codes: |
Notes:
STOP SMOKING SERVICE PHARMACOTHERAPY SPEND is the same as attribute FINANCIAL AMOUNT, where the FINANCIAL ALLOCATION OR SPEND TYPE FOR STOP SMOKING is National Code 'Total cost of pharmacoptherapies for the financial year'.
For guidance on how to calculate this, see the NHS Digital website at: NHS Stop Smoking Services Guidance Part 2 2016-17.
Change to Data Element: Changed Description
| Format/Length: | an3 |
| National Codes: | |
| Default Codes: |
Notes:
TREATMENT FUNCTION CODE (RECEIVING SERVICE) is the same as attribute TREATMENT FUNCTION CODE.
TREATMENT FUNCTION CODE (REFERRAL TO TREATMENT PERIOD) is the TREATMENT FUNCTION under which the PATIENT is to be treated or has been treated for the REFERRAL TO TREATMENT PERIOD. It may be the same as the MAIN SPECIALTY CODE of the CONSULTANT.
The valid codes for a REFERRAL TO TREATMENT PERIOD are:
Permitted National Codes:
| 100 | General Surgery |
| 101 | Urology |
| 110 | Trauma & Orthopaedics |
| 120 | Ear, Nose & Throat (ENT) |
| 130 | Ophthalmology |
| 140 | Oral Surgery |
| 150 | Neurosurgery |
| 160 | Plastic Surgery |
| 170 | Cardiothoracic Surgery |
| 300 | General Medicine |
| 301 | Gastroenterology |
| 320 | Cardiology |
| 330 | Dermatology |
| 340 | Thoracic Medicine |
| 400 | Neurology |
| 410 | Rheumatology |
| 430 | Geriatric Medicine |
| 502 | Gynaecology |
| X01 | All other TREATMENT FUNCTIONS not reported individually |
Change to Data Element: Changed Description
| Format/Length: | an2 |
| National Codes: | See TWO WEEK WAIT CANCER OR SYMPTOMATIC BREAST REFERRAL TYPE |
| Default Codes: |
Notes:
TWO WEEK WAIT CANCER OR SYMPTOMATIC BREAST REFERRAL TYPE is the same as attribute TWO WEEK WAIT CANCER OR SYMPTOMATIC BREAST REFERRAL TYPE.
For enquiries about this Change Request, please email information.standards@nhs.net
